This sketch shows the arrangement of #dentils in the classic variation of the #IonicEntablature. It shows the full layout, but most of the top is obscured by the top portion of the #cornice. Only the outside square shapes are actually visible.

Each #dentil has a square "footprint" that is 4 parts by 4 parts (32*32 units) and is 6 parts (48 units) tall. The spacing between each dentil is 2 parts (16 units).

Dentils project 4 parts (or 32 units) from the face of the #fascia on which they rest.

Each face of the fascia has 7 dentils with the middle dentil laterally centered and directly in front of the column axis. The 2 side dentils are on side faces, and that is apparent in the darker shading in the sketch at https://pixelfed.social/i/web/post/790782316675150160. Take the time to reconcile this with the numbers listed in #Scarlata's #PracticalArchitecture.

The 3D reconstruction from the #primaryProfileCurves is very similar to that of the #IonicPedestal, with #extrusion, #mitering, #joining, and #capping planar holes as described in https://pixelfed.social/i/web/post/790645054230337543 — just set the dentils aside, for now.

Once you have capped the #planarHoles to get a solid, analyze the edges of the solid in the #CAD program for #nakedEdges and #nonManifoldEdges.

Then, extrude the dentils outline (in the top view) to a height of 48 units (in the front view).

Now perform a #booleanUnion of the two solid shapes to get the complete #entablature.

Finally, check the edges of the solid in the #CAD program AGAIN for #nakedEdges and #nonManifoldEdges.

With this, we have finished two of the three main components of the #IonicOrder. There's a modern version of the Ionic entablature with #modillions, which I will describe later.

Next, we move on to the biggest, most conspicuous part of the order — the #IonicColumn.
Splines (@Splines@pixelfed.social)

There are two variations of the #IonicEntablature. The classic variation has #dentils, which are teeth-like structures shown here above the #frieze. The modern version has #modillions, which are projecting brackets under the #corona of the #cornice. Well, "modern" is a relative term. For designs that are more than 2000 years old, even an alteration 1000 years ago would qualify as modern. Although the sketch shows the #entablature with a square footprint, in practice, it runs the entire length of a #colonnade (multiple columns) or an #arcade (multiple arches). #CAD construction of the entablature is very similar to that of a #pedestal. The first step is to consult #Vignola's #RegolaArchitettura for the visual appearance, and then consult #Scarlata's #PracticalArchitecture for #VignolaProportions in tabular form. It is convenient to create a spreadsheet to convert the measurements given in Scarlata's book from module "parts" to your own model units based on your choice of value for the module parameter µ. Armed with these measurements, it is time to plot the points and draw the #primaryProfileCurves on our standard 2D grid with minor grid lines 8 units apart and major grid lines 32 units apart. In the first pass, skip the dentils and draw the profile curves for the rest of the moldings. Just as with the pedestal, I will show the macro-level plan as well as the detail plan. So, you don't have to go to Scarlata's book, but you know it's there if you want to. I will show the dentil arrangement in a subsequent post. Based on µ = 144, the classic Ionic entablature is 648 units (36 parts, or 4.5*µ) tall. Of this, the #architrave at the bottom is 180 units (10 parts, or 1.25*µ) tall, the frieze in the middle is 216 units (12 parts, or 1.5*µ) tall, and the cornice at the top is 252 units (14 parts, or 1.75*µ) tall.

Pixelfed

Here is how extrusions are made:
https://www.youtube.com/watch?v=76NcaTxFdE8

As you can see it's not a super accurate process. This is why it's not recommended to screw on linear rails and why some companies offer a machining service to make a flat surface. Another common practice is to let customers discover over-wrapped/twisted extrusions and then help via support.

#machines #3dprinting #extrusion #linearrail #motion

Custom Aluminum: Extrusion

YouTube
Himalayas formation may have destroyed at least 30% of continental crust in collision zone

Earth's continents are slowly moving across the planet's surface due to plate tectonics, culminating in regions of crustal expansion and collision. In the latter case, high temperatures and pressures lead to the reworking of the crust, affecting its composition, as well as that of the underlying mantle. Furthermore, when two continental plates collide, distinct topographic features are produced, namely mountain ranges, which are surficial manifests of Earth's thickened crust.

Phys.org

How to make an aluminum extrusion without extruding :D . Satisfying to watch!

Source: https://x.com/gunsnrosesgirl3/status/1838513221478617129

#aluminum #extrusion #SheetMetal #bending

Science girl (@gunsnrosesgirl3) on X

Precision

X (formerly Twitter)

No text duplication, no JS, no images save for CSS gradients, no long lists of values for anything (like text-shadow).

Just plain text + CSS gradients + blending + the magic of #SVG filters for extrusion + texture 🪄✨

Live on @codepen https://codepen.io/thebabydino/pen/gONbppb

#filter #svgFilter #cssGradient #blending #blendMode #noise #extrusion #code #textEffect #coding #frontend #web #dev #webDev #webDevelopment

No image dusty SVG filter effect

[Inspiration](https://dribbble.com/shots/21404553-Letter-Typography). --- If the work I've been putting out since early 2012 has helped you in any wa...

La fabrication de pailles bicolores [vidéo] - 2Tout2Rien

Voici une video de fabrication de pailles bicolores par extrusion.

2Tout2Rien
text-stroke double outline - no text duplication

[Inspiration](https://www.freepik.com/premium-vector/modern-clean-3d-gradient-inspirational-quote_3933193.htm). --- If the work I've been putting out...

This is semi-solid aluminum 3D printing! Unfortunately, according to Ric Fulop (CEO and co-founder of DesktopMetal), it can't be commercialized because the temperature control is very difficult and, when it fails, is very problematic. Nevertheless, it's an impressive demonstration.

Source: https://twitter.com/ricfulop/status/1774497991857946689

#3dprinting #metal #aluminum #extrusion #desktop_metal

Ric Fulop 🇺🇸/acc (@ricfulop) on X

@lucagrecoita Here is a video from 2019 I dug up demonstrating start stop and bridging.

X (formerly Twitter)

One thing that is rarely tested is that the faster you print, the weaker the layer adhesion. I'm pleased to finally see a video demonstrating this problem. These tests are only made with PLA and a single hotend, but it is a great start to see how quickly it can drop.

📽️ https://www.youtube.com/watch?v=SWKhB_4WTkc
By DIY Perspective

#3dprinting #speed #extrusion #hotend #3dptech #3dprinting_tech #layer #adhesion

How much WEAKER 3D Prints become at Higher FLOW RATES / SPEEDS? (DATA from 1000+ samples)
