Davide Bucci
PaulGoddammit, I rebuilt this substitution box a few years back but now it seams one of the switch wafers is conducting a bit and throwing off the resistance values 😑
#elecronics
#elecronics
Of course no project would be complete without a little bodge. I made a small mistake in the Ramdisk circuit. Not a big deal, but I had to add a bodge resistor 😅 I also put the NiMh battery pack in a safe place #Turbokit #Gem #S2 #elecronics #synth
Sunflower Björnskalle 🌻
Chi ha ucciso Il Conte?An old 3d model I made for a small amplifier #3dmodeling #freecad #FLOSS #design #amplifier #elecronics
Pepe MontfortEnsamblando…
#pdp11 #pdp1170 #elecronics #retro #retrocomputing #retrocomputers
AviancerBonus start up video, sweet sounds to my ears!
The VTX also works, though apparently I mounted the camera upside down - but that’s easy to fix :)
betsystreeter 🦥 🐄 🦇 🐧 🐙Today is Free Shipping Friday at INPRNT - yay! Get you or someone you like a new art friend. They do a really lovely job with their prints and cards.
https://inprnt.com/gallery/studioyesyes
#MastoArt #FediArt #Illustration #Vintage #Retro #1980s #1970s #Elecronics #ReelToReel #Atari #Mattel #Cassette #BoomBox #Turntable #Vinyl #PortableTV
Josef 'Jeff' SipekOn an #oscilloscope the waveform looks somewhere between a sine and a triangle wave. The 3.5Vpp is probably pushing the transistor a bit too hard and causing distortion. Either way, getting 7.55MHz with essentially no effort is pretty cool.
7.55MHz and 6.4uH yields a capacitance of 69pF. The tester design uses two 100pF capacitors making approx. 50pF in parallel with the crystal. The breadboard and wires could easily provide the other 19pF. #elecronics
Putting together the moodmeter circuit VOID Veneto Orientale Innovation District #esp32 #circuit #elecronics
