Using #FreeCAD, #freecadfriday to design #sheetmetal front covers for two electronics cabinets for the frankenmonster #CNC.

#FreeCAD #sheetmetal workbench unfolded the design and I manually added annotated folding step order and instructions.

The mostly finished cover, including perspex to see if any of the blinky LEDs are in Alarm state.

Very untidy WIP frankenmonster #cnc and both the new wall enclosures. Seems forget to take a more tidy finished or action shot!

Precision. Power. Performance.

Our Tile Profile Roll Forming Machine delivers perfect roofing sheets with high speed, heavy strength & zero compromise on quality.

Built for durability. Designed for productivity.

#TileProfileMachine #RollFormingMachine #RoofingSheetMachine #MetalRoofing #IndustrialMachinery #ManufacturingIndia #MakeInIndia #SheetMetal #EngineeringExcellence #JupiterRollForming #FactoryAutomation #RoofingSolutions #HeavyEngineering #MachineManufacturing #IndustrialGrowth

2 DAYS TO GO! 🚀
Witness LIVE Roll Forming Technology that’s redefining metal manufacturing.
Precision. Speed. Reliability — only at JUPITER 🔵⚙️

📍 IMTEX Forming 2026
🏢 Hall 4 | Stall B131
📅 21–25 Jan | BIEC, Bengaluru

👉 Don’t miss the LIVE DEMO!

#IMTEX2026 #IMTEXForming #RollFormingMachine #LiveDemo #MetalForming #ManufacturingIndia #EngineeringExcellence #IndustrialMachinery #MakeInIndia #JupiterRollForming #FactoryOfFuture #SheetMetal #Automation

How to make precise sheet metal parts (photochemical machining) [video]

https://www.youtube.com/watch?v=bR9EN3kUlfg

#HackerNews #photochemicalmachining #sheetmetal #precisionengineering #manufacturing #video #tutorial

I made baby duct!! IDK what for, just proof of concept for the lock seem. This seem requires some inner mandril work, which is why it is NOT used for long peices in my industry. I love this joint for small stuff though.

#sheetmetal #forming
