I made a thing!
Where project electronics meets music: creating my own custom MIDI Fader controller.
Featuring an #AdafruitFeather #RP2040, #CircuitPython and some lovely 100mm faders.

Full details:
https://www.technical-capers.info/post/the-midi-fader-caper

Movie Prop Electronics Hack Chat Takes Us Behind the Scenes

It's no surprise that the hacking and making community has traditionally had something of a love affair with movie props, especially those of the science fiction variety. Over the years we've seen folks put untold hours into incredible recreations of their favorite pieces of fictional gear -- and by the time this post goes out, our 2022 Sci-Fi Contest will be entering into the final stretch. So it's a safe bet that if you make your living by creating the electronics behind all that Hollywood movie magic, you'll find ours to be an especially welcoming community.

We were fortunate enough to see this in action this week when Ben Eadie stopped by to host the Hack Chat. It's no exaggeration to say that he's been living out what most of us would consider a dream, having worked on films from iconic franchises such as Star Trek and Predator. But perhaps his most enviable credit is that of propmaster for 2021's Ghostbusters: Afterlife , where he got the chance to work on the proton packs and ghost traps; arguably some of the most well-known props in the history of cinema.

Not bad for a guy who only recently got in the game. Ben spent 20 years working as an aerounatical engineer until a friend from his local maker space mentioned they were working on a film and could use a hand. Suddenly he found himself behind the scenes of Star Trek: Beyond in 2015, helping to design and fabricate one of the largest rotating sets ever made. He figures he must have done something right, because Hollywood has been calling ever since.

This anecdote about his first time working on a feature film helped answer what many wanted to know early on in the Chat, which was how one manages to get into the prop and special effects industry. Ben once again confirmed a truth well known to this community: that what you're capable of is far more important than where you went to school and what you studied. There's not a lot of formal education out there that can train you to make the impossible possible, and Ben says the majority of his day-to-day knowledge came from a lifetime of fiddling around with electronics. In fact, he attributes much of his professional success with hanging out in maker spaces, reading Hackaday, and watching YouTube. If that's the recipe, then we should all be in pretty good shape.

Over the last few years, Ben has been trying to pay that forward by documenting some of the tricks of the trade on his own YouTube channel. In a particularly interesting piece of marketing on Sony's part, some of Ben's videos have even been featured on the official Ghostbusters YouTube channel as part of a "Maker Monday" series. In fact, we first got in contact with Ben when he left a comment on our coverage of his "PKE Meter" prop build. This is the kind of advertisement we can get behind, and wish more companies would embrace the hacker and maker culture with this kind of interactive content. Ben says the best way to make initiatives like this more popular is to consume it -- if Sony sees people watching and sharing this kind of content, hopefully more will follow.

Of course, it wouldn't be a Hack Chat unless some arcane compartmentalized technical knowledge was dished out. In this case, several of the questions were about the unique challenges posed by operating custom electronics on a movie set. For example, Ben says he always uses addressable LEDs controlled by the APA102 chip as it offers an external clock pin that he can feed with a different frequency to avoid on-screen flickering. The radio spectrum also tends to be pretty noisy on set, so if at all possible, you want to make sure your gear has a wired connection. Otherwise, you'll need to get intimately acquainted with what other RF signals are being used on set so as not to interfere with the production.

Ben's creations include the Remote Trap Vehicle (RTV) from Ghostbusters: Afterlife.

But while some of the challenges he has to deal with might seem pretty foreign to us, the technology itself is in some cases more familiar than you might think. It turns out there's plenty of Sparkfun and Adafruit gear behind the scenes, with Ben specifically mentioning the Feather nRF52 as one of his go-to microcontrollers. Sometimes the graybeards on set grumble about his "consumer grade" tech, but when his gear is up and running in half the time, it's usually he who gets the last laugh.

Towards the end of the Chat, Ben says the most important thing he's learned over the years is to always have backups. His motto is "One is None", and if he can help it, he usually builds four of everything: that gives him two to learn from, and a pair to actually use for whatever the project is. Even if our own projects don't quite rise to the level of a key prop from a summer blockbuster, there's no certainly no harm in being prepared.

We want to thank Ben Eadie for taking the time to talk with the community and sharing some of his fascinating stories and tips with us. At the risk of sounding a bit sappy, stories like his are what motivates us here at Hackaday. If we can provide even a small part of the what it takes to help people like Ben achieve their goals, that's reason enough for us to keep the lights on.

The Hack Chat is a weekly online chat session hosted by leading experts from all corners of the hardware hacking universe. It 's a great way for hackers connect in a fun and informal way, but if you can't make it live, these overview posts as well as the transcripts posted to Hackaday.io make sure you don't miss out.

#hackadaycolumns #adafruitfeather #ghostbusters #hackchat #movieprops #props #startrek

Palm Portable Keyboard Goes Wireless

Long ago when digital portables where in their infancy, people were already loath to type on tiny keyboards, stylus or not. So Palm made a sweet little portable keyboard that would fold up and fit in your cargo pocket. And what do we have now for luxury typing on the go? Rubber roll-up jelly keebs? That's a hard no from this scribe.

But why mess with the success of the the Palm Portable Keyboard? It just needs to be updated for our times, and that's exactly what [Xinming Chen] did with their PPK Bluetooth adapter.

Inspired by the work of [cy384] to make a USB adapter as well as [Christian]'s efforts with the ESP32, [Xinming Chen] points out that this version is more power efficient, easier to program, and has a built-in Li-Po charging circuit. It also uses the hardware serial port instead of the software serial, which saves brainpower.

There's really not much to this build, which relies on the Adafruit Feather nRF52840 and will readily work with Palm III and Palm V keyboards. Since the PPK is RS-232 and needs to be TTL, this circuit also needs a voltage level inverter which can be made with a small handful of components. We love that there's a tiny hidden switch that engages the battery when the adapter clicks on to the connector.

The schematic, code, and STL files are all there in the repository, so go pick up one of these foldy keebs for cheap on the electronic bay while they're still around. Watch the demo video unfold after the break.

Want an all-in-one solution for typing on the go? Check out the history of tiny computers.

#peripheralshacks #wirelesshacks #adafruitfeather #nrf52840 #palm #palmportablekeyboard

Guitar Pickguard Adds MIDI Capabilities

For a standard that has been in use since the 1980s, MIDI is still one of the most dominant forces on the musical scene even today. It's fast, flexible, and offers a standard recognized industry-wide over many different types of electronic instruments. Even things which aren't instruments can be turned into musical devices like the infamous banana keyboard via the magic of MIDI, and it also allows augmentation of standard instruments with other capabilities like this guitar with a MIDI interface built into the pick guard.

[Ezra] is the creator of this unique musical instrument which adds quite a few capabilities to his guitar. The setup is fairly straightforward: twelve wires run to the pick guard which are set up as capacitive sensors and correspond with a note on the chromatic scale. Instead of using touchpads, using wires allows him to bend away the "notes" that he doesn't need for any particular piece of music. The wires are tied back to an Adafruit Feather 32u4 microcontroller behind the neck of the guitar which also has a few selectors for changing the way that the device creates tones. He can set the interface to emit single notes or continuously play notes, change the style, can change their octave, and plenty of other features as well.

One of the goals of this project was to increase a guitar player's versatility when doing live performances, and we would have to agree that this gives a musician a much wider range of abilities without otherwise needing a lot of complex or expensive equipment on stage. We've seen a few other MIDI-based builds focused on live performances lately, too, like this one which allows a band to stay in sync with each other.

#musicalhacks #32u4 #adafruitfeather #capacitive #guitar #live #microcontroller #midi #music #performance #pickguard #touch #wires

Portrait of a Digital Weapon

Over the years, artists have been creating art depicting weapons of mass destruction, war and human conflict. But the weapons of war, and the theatres of operation are changing in the 21st century. The outcome of many future conflicts will surely depend on digital warriors, huddled over their computer screens, punching on their keyboards and maneuvering joysticks, or using devious methods to infect computers to disable or destroy infrastructure. How does an artist give physical form to an unseen, virtual digital weapon? That is the question which inspired [Mac Pierce] to create his latest Portrait of a Digital Weapon.

[Mac]'s art piece is a physical depiction of a virtual digital weapon, a nation-state cyber attack. When activated, this piece displays the full code of the Stuxnet virus, a worm that partially disabled Iran's nuclear fuel production facility at Natanz around 2008.

It took a while for [Mac] to finalize the plan for his design. He obtained a high resolution satellite image of the Iranian Natanz facility via the Sentinel Hub satellite imagery service. This was printed on a transparent vinyl and glued to a translucent poly-carbonate sheet. Behind the poly-carbonate layer, he built a large, single digit 16-segment display using WS2812 addressable LED strips, which would be used to display the Stuxnet code. A bulkhead USB socket was added over the centrifuge facility, with a ring of WS2812 LEDs surrounding the main complex. When a USB stick is plugged in, the Stuxnet code is displayed on the 16-segment display, one character at a time. At random intervals, the LED ring around the centrifuge building lights up spinning in a red color to indicate centrifuge failure.

The 16-segment display was built on an aluminum base plate, with 3D printed baffles to hold the LED strips. To hold the rest of the electronics, he built a separate 3D printed frame which could be added to the main art frame. Since this was too large to be printed in one piece on the 3D printer, it was split in parts, which were then joined together using embedded metal stud reinforcement to hold the parts together. Quite a nice trick to make large, rigid parts.

An Adafruit Feather M0 micro-controller board, with micro SD-card slot was the brains of the project. To derive the 5 V logic data signal from the 3.3 V GPIO output of the Feather, [Mac] used two extra WS2812 LEDs as level shifters before sending the data to the LED strips. Driving all the LEDs required almost 20 W, so he powered it using USB-C, adding a power delivery negotiation board to derive the required juice.

The Arduino code is straightforward. It reads the characters stored on the SD-card, and sends them sequentially to the 16-segment display. The circular ring around the USB bulkhead also lights up white, but at random intervals it turns red to simulate the speeding up of the centrifuges. Detecting when the USB stick gets plugged in is another nice hack that [Mac] figured out. When a USB stick is plugged in, the continuity between the shell (shield) and the GND terminal was used to trigger a GPIO input.

Cyber warfare is here to stay. We are already seeing increasing attacks on key infrastructure installations by state as well as non-state actors around the world. Stuxnet was one of the first in this growing category of malicious, weaponized code. Acknowledging its presence using such a physical representation can offer a reminder on how a few lines of software can wreak havoc just as much as any other physical weapon. Check out the brief project video after the break.

#art #securityhacks #16segmentdisplay #3dprinting #adafruitfeather #arduino #build #concept #countdowntozeroday #cyberart #cyberwar #electronics #guilded #leds #microcontrollers #militaryportraiture #portrait #portraitofadigitalweapon #segmentdisplay #stuxnet #usbc #virus #weaponsportraiture

RT @[email protected]

You didn’t think I quit making weird stuff , now did ya? Introducing a barometric trigger wifi beacon flooder... #esp8266 #wifihackers #adafruitfeather #neopixel #mpl3115a2 (yes, I technically could run a deauth attack , but I like beacon floods more) #w… https://ift.tt/30kKkuE
