Custom Macro Keyboard With RGB Lighting

From the smallest 60% keyboards for those with no desk space to keyboards with number pads for those doing data entry all day, there's a keyboard size and shape for just about everyone. The only problem, even with the largest keyboards, is that they're still fairly limited in what they can do. If you find yourself wishing for even more functionality, you might want to build something like this custom macro keyboard with built-in LED backlighting.

Rather than go with a standard mechanical keyboard switch like a Cherry MX, this build is based around TS26-2 pushbuttons with built-in LED lighting. [atkaper] only really needed one button for managing the mute button on MS Teams, but still built a total of eight switches into this keyboard which can all be individually programmed with different functions. The controller is an Arduino Leonardo and the enclosure was 3D printed.

Paired with the classic IBM Model M keyboard, this new macro keyboard adds plenty of functionality while also having control over LED backlighting. Macro keyboards are incredibly useful, especially with their ability to easily change function with control over the software that runs on them. The key to most builds is the 32U4 chip found in some Atmel microcontrollers which allows it to easily pass keyboard (and mouse) functionality to any computer its plugged in to.

#peripheralshacks #32u4 #3dprinted #arduino #custom #keyboard #led #leonardo #macro #pushbutton #switch #usb

Guitar Pickguard Adds MIDI Capabilities

For a standard that has been in use since the 1980s, MIDI is still one of the most dominant forces on the musical scene even today. It's fast, flexible, and offers a standard recognized industry-wide over many different types of electronic instruments. Even things which aren't instruments can be turned into musical devices like the infamous banana keyboard via the magic of MIDI, and it also allows augmentation of standard instruments with other capabilities like this guitar with a MIDI interface built into the pick guard.

[Ezra] is the creator of this unique musical instrument which adds quite a few capabilities to his guitar. The setup is fairly straightforward: twelve wires run to the pick guard which are set up as capacitive sensors and correspond with a note on the chromatic scale. Instead of using touchpads, using wires allows him to bend away the "notes" that he doesn't need for any particular piece of music. The wires are tied back to an Adafruit Feather 32u4 microcontroller behind the neck of the guitar which also has a few selectors for changing the way that the device creates tones. He can set the interface to emit single notes or continuously play notes, change the style, can change their octave, and plenty of other features as well.

One of the goals of this project was to increase a guitar player's versatility when doing live performances, and we would have to agree that this gives a musician a much wider range of abilities without otherwise needing a lot of complex or expensive equipment on stage. We've seen a few other MIDI-based builds focused on live performances lately, too, like this one which allows a band to stay in sync with each other.

#musicalhacks #32u4 #adafruitfeather #capacitive #guitar #live #microcontroller #midi #music #performance #pickguard #touch #wires

Does anybody know how to change the USB current draw that an Arduino type device requests when you plug it in? The Thumble its rejected by iOS devices because it requests 500ma, which is far more than it needs.

I know this is changeable in the DFU bootloader used by QMK mechanical keyboards, but I am using the default Caterina bootloader that works with the vanilla Arduino IDE, to make the project easier for anyone to make.

The board is an Adafruit Feather 32u4 basic proto.

#arduino #32u4
