e_es Jul 20, 2023

Mit #Freecad habe ich mich endlich man an die #Assembly4 #Workbench gewagt und einen ersten Versuch gestartet. #done

morgan Dec 25, 2022

More progress on my 'Flatpack' #FreeCAD Workbench idea. The LCS points are already places as part of the #Assembly4 workflow, this Macro takes those points and creates Pockets or Pads based on the position of the Point, inside or outside the Bounding Box. https://git.oit.cloud/morgan/Flatpack_WB/src/branch/development/Macro/FlatpackWB.FCMacro

Flatpack_WB

A FreeCAD workbench for creating CNC (or laser) flat pack constructions. It uses Assembly 4 to mark locations for tabs or fingers.

Oit Cloud Consulting Services

morgan Dec 7, 2022

ok.... I have this dream #FreeCAD workbench to simplify one of my most common workflows, flat pack plywood construction. The issue is designing slot/tab at the sketch level is a pain, especially when making major changes like changing stock thickness and variable stock thickness (narrow finger, thick slot). My goal is to use #Assembly4 LCS points to set locations and have the WB generate slots and finger. Brain dump here. https://git.oit.cloud/morgan/Plywood_WB

Plywood_WB

A FreeCAD workbench for creating CNC (or laser) constructions. It uses Assebly4 to mark locations for tabs or fingers.

Oit Cloud Consulting Services

morgan Dec 3, 2022

#FreeCADFriday Revisiting a project as my 'I'm unemployed and will work on what I wish!' project. I'm really enjoying my approach on this project. Each piece of the #Assembly4 are created in the PartDesign WB, top down as if cut from plywood (cause they will be) and put together using Assembly 4. This allows a ton a flexibility because my part histories stay very shallow. DatumPlanes, offset with the same Spreadsheet values used for Pads, are used to not need to worry about Face names changing.

Homo Particeps Nov 9, 2022

A rough idea for butterfly-like "pocket scissors", inspired by the #Baliscissors, but simpler and ~8 cm short. Made with #FreeCAD #Assembly4

The pins will be replaced by the ends of a torsion spring (like those in clothespegs) that would sit in the middle of the axis. They connect handle and blade: Pushing the blades together when the handles are folded inwards or pushed together to make a cut.
