Work in progress - Taking @Liz29's hand-drawn sketch into 3D using #FreeCAD, and using CAM to create machine instructions for #CNCRouter

#Drawing #ProductDesign #OpenSource #MakerSpace

Jonathan / JRO 8h ago

Working with @Liz29 to design & build a Japanese-style sushi board, to be carved into 3D using a CNC router, and then marked with Japanese characters using a CO2 laser. Started with her hand-drawn sketch, designed in 3D using #FreeCAD (on #Mint #Debian #Linux). Used FreeCAD CAM (computer aided manufacturing) tool to design the machine instructions for the #CNCRouter

#MakerSpace #OpenSource

Uwe 13h ago

FreeCAD 1.1 is Finally HERE — It’s a GAME CHANGER ! (Major Updates you missed)

https://www.youtube.com/watch?v=bYdobpjTypg

#FreeCAD

FreeCAD 1.1 is Finally HERE — It’s a GAME CHANGER ! (Major Updates you missed)

YouTube

Uwe 13h ago

For a reason:

STOP using FreeCAD WRONG! Do this INSTEAD (Workflow & Tips)

https://www.youtube.com/watch?v=JjFh8vtMBC8

#FreeCAD

STOP using FreeCAD WRONG! Do this INSTEAD (Workflow & Tips)

YouTube

Show thread

Dr Footleg (he/him)13h ago

@chrishuck Also all the joint constraint markers have moved a long way from the assembly, so when I snap to view all, the assembly is tiny on screen as the joint markers are miles away. I don't know how that happened. For comparison, this mechanism behaves very well in Solidworks which I also use. But I would really like to be able to share my project in #FreeCAD if I can get it to work.

Benjamin 18h ago

#FreeCad hat für mich mittlerweile SolidEdge auf Arbeit überflüssig gemacht. Ja ich benutze CAD auch nur für Aufträge für die feinmechanische Werkstatt und internen 3D-Druck, aber ich vermisse nichts und finde FreeCad in manchen Bereichen sogar deutlich intuitiver zu bedienen. Deswegen: Ein Hoch auf freie Software!
