Matt Simmonds aka "4mat": working on a 7 channel SID driver. (3 sid channels, 4 mixed waveforms out of the volume register. 6581 only)

#compo #SidPlayer #SID6581 #MOS6581 #music #Chiptune #4mat #Anarchy #commodore #CBM #C64 #soundchip #8bit #MattSimmonds #retrocommuter #tracker #80s #90s #Geek

ESP32 SID Player hat

https://makertube.net/w/nPuMa82atqRk3bD3XDW8zs

#Retrocomputing & #SciFi trivia: During his brief tenure as Compute! Magazine’s book editor in 1983, #EndersGame author #OrsonScottCard contracted Craig Chamberlain to write #programming books on the #Commodore64 based on the latter’s work on the #Atari 400 and 800 Pokey Player #music system.

Chamberlain’s second Compute! book, “All About the #Commodore 64, Volume Two,” was the first appearance of #Sidplayer, which would become the US's most popular #C64 music system.

https://www.sidplayer.org/history_promotional.html

thanks #JLCPCB for flawlessly printing all my design errors 🤭

along with discovering the result of my own horrors, it brought an unexpected twist: now it's a board that works both with D32Pro and S3Pro

#ESP32 #SIDPlayer #SID6581 #C64

finally got some sound out of this SID Player for ESP32 I designed while learning Kicad 🥳

the whole lot of mistakes I made can't be enumerated here, but the biggest one was inverting pins D{0-7} position in the schema editor 🤦‍♂️

ironically this is the only error I could recover from by using software whereas other "patches" would involve cutting tracks or adding wires

#ESP32 #SID6581 #MOS6581 #C64 #SIDPlayer #ESP32SID #JLCPCB #Kicad
