Martin Piper (he/him) 💙💛🌻💉I thought I would add a test menu, like the original arcade version, for #MegaWang After Burner... This will make it easier to test my new Audio3 PCBs.
Q. How many connectors do you want on your #MegaWang backplane?
A. Yes
Thank you @PCBWayOfficial and @SGirl0311 for the extra pretty swag this year. My #Commodore64 and #MegaWang are nice and comfortable.
It's been a couple of months since the last #Commodore64 #MegaWang hardware update. I've been pondering ways to put this stack into a case and also adding a CPU card. This is targeted as a TTL teaching aid project.
https://www.youtube.com/watch?v=p50d_DsQ8WY
https://www.youtube.com/watch?v=p50d_DsQ8WY
MegaWang 2000 Turbo Edition - 22 - SDK 1 0 0 7
#MegaWang hardware with scaling and rotation graphical effects running on my trusty old #Commodore64
@PCBWayOfficial delivered another working board. Really very pleased with how these SMT boards are progressing.
https://youtu.be/RErpMdBNh-w
@PCBWayOfficial delivered another working board. Really very pleased with how these SMT boards are progressing.
https://youtu.be/RErpMdBNh-w
MegaWang 2000 Turbo Edition - 23 - Mode7
This new board adds pixel layer combination operations to my #MegaWang Commodore 64 graphics expansion hardware. This adds stencil tests, dithering, and logical operations to increase the graphical effects available to the user. Thanks to @PCBWayOfficial
https://youtu.be/3mcPPXWSE9A
https://youtu.be/3mcPPXWSE9A
MegaWang 2000 Turbo Edition - Combination layer
Unboxing and testing of my latest PCB project. This board adds vector graphics capability to my #MegaWANG graphics expansion hardware for the #commodore64
Thanks to @PCBWayOfficial for delivering a working assembled board in 15 days!!
MegaWang 2000 Turbo Edition 19 Vector graphics layer
Finally fixed a couple of issues with the APUboard(like the Amiga blitter+copper). The crazy stack of boards renders a bit more than an Amiga 500 was capable of, but using a Commodore 64.
The main project page with dev logs and downloads: https://martin-piper.itch.io/bomb-jack-display-hardware
MegaWang 2000 Turbo Edition 14 New user port interface board.
Testing and bodge fixing the new SMT user port interface board with my trusty Commodore 64. #MegaWang #RetroTTL #RetroTTLVideoCard #C64 #Commodore64
https://www.youtube.com/watch?v=FFWJYxaOjBs
Testing and bodge fixing the new SMT user port interface board with my trusty Commodore 64. #MegaWang #RetroTTL #RetroTTLVideoCard #C64 #Commodore64
https://www.youtube.com/watch?v=FFWJYxaOjBs
MegaWang 2000 Turbo Edition 14 New user port interface board
Using my trusty #Commodore64 and the latest #MegaWang APU PCB V9.4 build, this "Shadow of the Beast" title screen and game demo shows the graphical raster and parallax scrolling effects provided by the extra #electronics.
https://www.youtube.com/watch?v=L82BmRnG9iw
https://www.youtube.com/watch?v=L82BmRnG9iw
