High-end 25MP global shutter camera with 10GbE interface is designed for NVIDIA Holoscan platform
Leopard Imaging LI-IMX530-10GigE-NL is a high-end 25MP global shutter camera designed specifically for the NVIDIA Holoscan edge AI platform. The camera utilizes a 10GbE interface for high-bandwidth, low-latency data transmission, making it suitable for gesture recognition, iris scanning, head roll, and eye tracking. At the core of the camera module is the Sony IMX530, a 1.2-inch CMOS sensor with 5328 × 4608 resolution and a 2.74 μm pixel size. The sensor data is handled by a Lattice CertusPro-NX FPGA, and a Marvell 10GbE PHY takes care of high-bandwidth data transfer to GPU systems. The camera supports NVIDIA Jetson AGX Orin, IGX Orin, and Thor platforms. LI-IMX530-10GigE-NL specifications: FPGA – Lattice CertusPro-NX FPGA 52K to 96K logic cells 7.3 Mb total embedded memory External LPDDR4 memory support Up to 156x (18 x 18) multipliers within sysDSP blocks for AI/ML workloads 10 Gigabit Ethernet PCS blocks Image sensor Sony IMX530 Diagonal 19.3 mm
