Thanks Jason! Be sure to check out his Motorola 68000 CPU exhibit at VCF SoCal 2026!

#AtariProjects #Atari #VCFSoCal #VCF #VCFed #VCFederation #Festivals #VintageComputing #RetroComputers #RetroGaming #FUN

Diagnosis, Repair & Mods of Retro is Jason's exhibit. Check it out and thank him for supporting the fest!

#AtariProjects #Atari #VCFSoCal #VCF #VCFed #VCFederation #Festivals #VintageComputing #RetroComputers #RetroGaming #FUN

Thank You Atari Projects for your Sponsor Support of VCF SoCal 2025! :)

#AtariProjects #Atari #VCFSoCal #VCF #VCFed #VCFederation #Festivals #VintageComputing #RetroComputers #RetroGaming #FUN

Had fun tonight using the four channels of my Siglent SDS 1104X-E oscilloscope to monitor multiple pins of the 6502 CPU from my Atari 800XL. Fun to see in action! https://atariprojects.org/2025/01/01/use-a-multichannel-oscilloscope-to-test-multiple-pins-of-an-integrated-circuit-simultaneously-15-30-mins/ #atari8bit #retrocomputing #atariprojects
Use a Multichannel Oscilloscope to Test Multiple Pins of an Integrated Circuit Simultaneously (15-30 mins) – Atari Projects

Replace the Track 0 Sensor on an Indus GT Floppy Disk Drive for the Atari 8-Bit Computers (30-60 mins) – Atari Projects

Did you know that the Sys-Check II device can test the RAM & ROM of an Atari 8-bit computer even if it won't boot (i.e. dead test) https://atariprojects.org/2024/11/16/purchase-the-sys-check-device-for-diagnostic-testing-the-ram-and-rom-of-atari-xl-xe-8-bit-computers-5-10-mins/ #atariprojects #atari8bit #retrocomputing
Purchase the Sys-Check Device for Diagnostic Testing of the RAM and ROM of Atari XL/XE 8-Bit Computers (5-10 mins) – Atari Projects

Here is a relatively simple project that adds S-video output to an Atari 800XL by soldering a single wire to connect the chroma signal to the 5-pin DIN https://atariprojects.org/2024/11/07/connect-the-chroma-signal-to-the-5-din-video-jack-of-an-atari-800xl-for-s-video-output-1-2-hrs/ #atariprojects #atari8bit
Connect the Chroma Signal to the 5-Din Video Jack of an Atari 800XL for S-Video Output (30-60 mins) – Atari Projects

I made some videos of the oscilloscope waveforms for each of the 40 pins of a working 6502 Sally CPU on an Atari 800XL. I hope this helps others see what is expected on a working system. https://atariprojects.org/2024/10/19/troubleshoot-the-6502-processor-on-your-atari-8-bit-computer-circuit-board-using-an-oscilloscope-15-30-mins/ #atari #atari8bit #atariprojects
Troubleshoot the 6502 Processor on Your Atari 8-Bit Computer Circuit Board Using an Oscilloscope (15-30 mins) – Atari Projects

I published several posts this weekend on the Atari Projects website on tools for repairing 8-bit computers. Covered are multimeters & oscilloscopes, desoldering irons & hot air guns, and other useful items https://atariprojects.org/ #atari8bit #retrocomputing #atariprojects
Atari Projects – Fun projects for your Atari 8-bit home computers and video game consoles
