A technical deep-dive for the #Electronics and #EmbeddedDev community on a pragmatic audio solution for industrial applications.

It's a great example of how straightforward, well-executed technology can significantly enhance usability and safety in demanding fields using the KT142C SOP-16 voice chip.

Read the full design and implementation guide:https://lnkd.in/dwaECMNX

#Tech #HardwareDesign #Agriculture #VoiceInterface #Microcontroller #OpenHardware #PrecisionFarming

Detailed technical share for the #DIYElectronics and #EmbeddedDev community.

very low power consumption.
If you're working on appliances, toys, or IoT gadgets, this chip can save you significant development time.

Read the full design note here: https://lnkd.in/gUTAR69q

#Tech #Electronics #HardwareDesign #VoiceInterface #Microcontroller #IoT #Engineering #OpenHardware

A developer's note on enabling BLE Transparent Transmission for the BT401 Dual-Mode Audio Bluetooth module.

Data Flow:

Your MCU can send any data (non-AT-commands) over UART, and it will be transparently transmitted via BLE.

Any data sent from a mobile app is forwarded directly to your MCU, The module itself won't process it, giving your application full control.

https://www.linkedin.com/pulse/how-enable-ble-transparent-transmission-bt401-dual-mode-junluan-tsui-d0nwc

#Bluetooth #BLE #TransparentTransmission #EmbeddedDev #IoT #Audio #HardwareDesign #BT401

A clear guide for developers navigating the certification process for the KT6368A Bluetooth chip. It explains why you need to flash unique firmware to pass FCC, BQB, CE, and KC certifications. The post also includes tips on handling hardware-related certification failures. Essential reading for anyone bringing a Bluetooth product to market.

#KT6368A #Bluetooth #FCC #BQB #CECertification #KCCertification #IoT #HardwareDesign #EmbeddedDev #OpenSourceHardware #TechGuide

https://www.linkedin.com/pulse/operation-guide-kt6368a-bluetooth-chip-pass-fcc-bqb-kc-junluan-tsui-po5tc

Exploring the KT142A voice chip? Here’s a robust guide for developers:

🔹 Audio Prep: Optimize MP3s (remove silent segments, 16kHz recommended)
🔹 Hardware: 3V-5.2V power, PWM/DAC options, BUSY pin diagnostics
🔹 Debugging: Fix playback truncation (reduce amp capacitor to 10nF)

Real-world example: Bus announcements & Community access control

#EmbeddedDev #VoiceInterface #Electronics #KT142A #OpenSourceHardware

https://www.linkedin.com/pulse/from-kt142a-voice-chip-practical-project-development-guide-tsui-2tflf

🚀 CanAir.IO firmware now runs in-browser! Huge thanks to @WokwiMakers for their amazing CLI tools that made this possible.

#canairio #wokwi #GitHub #EmbeddedDev #IoT #esp32

I screwed up so hard.

Does anyone in #EmbeddedDev have the document "Programming Sharp Memory LCDs"? It was a document they themselves created for the obvious purpose and no longer host.

I thought I was keeping all my datasheets locally but I can't find these ones.

I've just pushed an update to my #blog!
In this post:

• Get yourself some updates regarding the state of PETI, my ongoing virtual pet development project!
• Patch rants with unusual brevity about decisions made by major corporations.
• True facts about Patch's Starfield, Fallout 4, and Dwarf Fortress playtime statistics in Steam.

https://www.arcanalabs.ca/news/labnotes/peti/2025/01/13/peti-update.html

#blog #virtualpet #embeddeddev

So among the things I did yesterday that I was putting off for fear of their complexity, but which later turned out to be quite straightforward, was writing a custom export module for the font editing tool we've been using for PETI. This new exporter lets anyone use fontedit to spit out a font in a much more standard format, which can then be edited with any additional tooling of their choice which supports it.

It's an unfortunate bit of yak-shaving, but it should get me unblocked on creating the new glyphs I needed to finish the evolution features and get the next update out to you guys much more quickly.

#blog #embeddeddev #electronicsdiy #virtualpet #BoostWelcome

https://www.arcanalabs.ca/news/labnotes/peti/2024/01/24/peti-font-escape.html

(As always, this toot is the anchor for the comment system for the blog post it links to)
