For an upcoming experiment, I need to know how accurate my #Keithley 2400 is at nA outputs (God I absolutely love that box… 🥰), but I also wanted to see how well my 6.5digit GDM-9061 multimeter tagged along..

Enter the HP 3458A… 💪🏼😎

Connected them all in series and although the set point on the 2400 is a bit off from reality, it’s own current measurement is bang on. At 20nA 🤯😃 And the 9061 multimeter was in agreement as well, even at such low currents.

Ready for next step, stay tuned 😎😎

#electronics #testandmeasurement #rfengineer #electronicsengineering

Søren Kjærsgaard Jan 17

At the night of the legendary capacitor explosion we also hosted a BYOD Oscilloscope night, where ppl could bring their instruments and learn more about them, common pitfalls, how to do basic measurements, more advanced stuff, etc.

Surprisingly many electronics enthusiasts don’t have an oscilloscope, and even more surprising, many don’t really know how to use the instrument they have.

The evening opened many new doors to the participants - I think everyone were happy 😃

#hamradio #electronics #electronicsengineering #rfengineer #testandmeasurement

Søren Kjærsgaard Jan 13

Suddenly a loud bang from the lab at the local #hamradio club ‼️ 💥🤯

Luckily nothing happened to the people in there, but I guess it’s safe to say that this vintage capacitor decided to quit its job 😂

Always wear safety glasses 🥽 when testing and troubleshooting #electronics, especially if it’s vintage gear where you have no knowledge of its state and health☝🏼

#electronicsengineering #vintageelectronics #vintagerepair
