Jarkko SakkinenI’ve had so much fun with the 486 SX-33 lately that I haven’t even touched the Switch 2 I got over the weekend.
I’m putting together a devkit for the MiSTeR FPGA ao486 core, and more generally an environment for retro game and demo-style projects. Toolchains in this space have been fairly grim so far: DJGPP, Turbo C++, or Watcom C/C++.
AO486 DEVKIT- GCC and LLVM support. COM output is supported through a linker script, and EXE output is supported as well. A Lua script prepends an MZ header to the EXE.
- A chain loader switches to protected mode and loads the program into extended memory.
- Rather than relying on DOSBox or 86Box, I tuned QEMU very carefully. It now feels surprisingly close to the ao486 core in practice.
- If this were a 386 SX devkit, I would probably have gone with flat real mode or so-called “unreal mode”. On a 486, though, the
0x66and0x67prefixes used for 32-bit instructions already eat into performance on what is still a fairly modest CPU. The pipeline is only 16 bytes long. - There is a small proof of concept included, but only the bare minimum. I’m saving the more interesting material for my own retro projects. The idea is to provide a blank canvas built on a much better SDK.
486.mdcovers 486-specific assembly optimisation details. In practice, it is quite a different beast from either a 386 or a Pentium. This is the sort of material that is fun to read on its own, so it felt worth writing.- The package includes the Unscii font, apparently pulled from GitHub, though I can no longer find the exact source URL. The original project is here: http://viznut.fi/gfx/fonts/
- It also includes
tmodplay, a MOD player. Unfortunately, the Sound Blaster 16 implementation in ao486 is pretty awful. For that era of PC hardware, the only really good option was the Gravis Ultrasound. - The target configuration has 16 MiB of RAM. That would have been an unusual combination back in the day, but those are the ao486 defaults, so I’m leaning into a kind of retro-modern setup. The other default was some completely absurd number.
- There is also a proof-of-concept demo with a four-layer parallax scroller and various informational texts.
I’m not really a game or demo developer myself, but I can at least provide much better SDKs, so I felt like fixing one long-standing problem in the retro scene. It is released under the MIT license so people can do whatever they like with it.
I should also check whether that FPGA core supports VESA 2.0, because that would allow 320x240 with chunky pixels. VESA 1.x was awful.
