And there it is. I probably spent more time figuring out how the jack nuts and LEDs go in, than actually soldering parts. Seems someone forgot to update their build documentation for this specific model.. Breeze to build anyway 🥰
Best bits in the kit - that tool for the jack nuts and the pcb snap-off bits. Latter are great for many #Diy builds, really any use wherever you need both reasonably thin and rigid base material.
AY3-8910 tries to do SID voice. Syncing the internal modulator to the bass note periods for pretend pwm. Not bad at all for the humble AY without resorting to the intense cpu control of the volume registers, as might be found in much demoscene stuff.
#ay38910 #soundchip #chiptune #zxspectrum #amstradcpc #vectrex #sidchip #c64 #eurorack #eurorackmodule #thegoat
More AY3 / YM2149 sound chip action. AY300 and YM300, each as a three voice stack, with some SID drums as the driver. Lots of lovely trills when it gets going and some buff octaving C64 style bass line action. The kind of tune that'd definitely have had the telly cranked in my school daze. It's awesome👾🕹📺🙂
#AY38910 #ym2149 #psg #programmablesoundgenerator #soundchip #chiptune #eurorack #thegoat #zxspectrum #atarist #sidchip #eurorackmodule
Finished. AY300 and YM300 chip tune oscillators. Chip tune oscillators running the AY3-8910 and the YM2149. Both more or less the same. The YM isn't as dirty as the AY and not quite as gnarly. Both get 10/10 for retroness and in sounding like ZX spectrum and Atari ST daze. Especialy with the modulator accessible to pull off 'sid voice' kinds of tricks that can be found in the demoscene.
#x1l3 #AY38910 #ym2149 #chiptune #atarist #zxspectrum #psg #eurorack #eurorackmodular #eurorackmodule
Resonance fine tuning. Throw some stuff together, hit cell 1 with fast envelope CV to rez and cut to get the zap, a second envelope hits it off beat to get the almost sidechain compressor like buzzy wowwwwww. Sidguts does the C64 arp stuff through some slow cutoff sweeping on cell 4. All very 'Reznor - social network' - alike.
#eurorack #eurorackmodule #resonantfilter #zap #sidguts a bit like #thesocialnetwork and #trentreznor kinds of things
And what would a filter array in the making be without doing this with it. I'll meet you on the dark side of the moon 🌒
#eurorack #eurorackmodule #resonantfilter #pinkfloyd #darksideofthemoon #ontherun
Testing a prototype filter array build. One filter is better than none. Four filters are better than one.Tweaking and deciding what's nice and what's not. Ended up making a fine impression of mesh or depeche mode.
#eurorack #eurorackmodule #resonantfilter #filterarray #mesh #depechemode
Unveiling the Mutant Machine - Erica Synths' Evolution of Analog Percussion: https://www.reviewspace.info/unveiling-the-mutant-machine-erica-synths-evolution-of-analog-percussion
#EricaSynths #MutantMachine #EurorackModule #AnalogPercussion #HexinverterÉlectronique #TR909 #ElectronicMusic #MusicGear #TechNews #ReviewSpace
