#computemodule5 Carrierboard Geekworm X1501

https://raspithek.de/hardware/single-board-computer/raspberry-pi/cm5-carrierboard-geekworm-x1501/

NEW Video 👇👇👇

Build A Tiny PC With @raspberrypi Compute Module 5 IO Board from @seeedstudio | CM5 Minima IO Board

👉Full Video : https://youtu.be/ODERd8NbuYo

#computemodule5 #io #iot #pc #raspberrypi

I've been waiting a long time for this to happen. Couldn't think of anyone better than #argon40 to do it. #raspberrypi laptop that uses the #cm5 #computemodule5

https://www.kickstarter.com/projects/argonforty/upton-one-the-true-raspberry-pi-compute-module-5-laptop

Welcome to KAMPi! My Self-Built Digital Camera

Hello everyone! I have always wanted to build my own digital camera. But not just any digital camera, one I would actually use like a regular point-and-shoot camera. I wanted something that would give me traditional feel, but still shoot in 4K. A tall order for sure, and to top it all off, I wanted to build everything myself. Well the time has come. . . Please join me in welcoming KAMPi! Check out my build below.

Why KAMPi?

KAMPi is short for “Kampay” which is Tagalog slang for “Kanpai” the Japanese word for cheers. It also sounds like CAMPi another way of saying Pi Cam, which is exactly what it is – a digital camera built using a Raspberry Pi mini computer.

What’s Inside?

I built KAMPi from the ground up: selected, wired, and soldered the hardware electronics, 3D printed the parts, and prepared the software.

For the computer internals, I chose to use a Raspberry Pi Compute Module 5 which rides on a Waveshare Nano A. The camera imager and lens are from Raspberry Pi as well, the Raspberry Pi High Quality Camera with the 16mm Telephoto Lens. For the display I used a Pimoroni HyperPixel 4.0″ Hi-Res Display. The display is connected to the Waveshare Nano A via GPIO pins (the header of the Nano I soldered myself). Everything is packed together in a tight package shown above.

For the power electronics I chose to use a Pimoroni LiPo SHIM I purchased from Adafruit. I wired it up with a on/off switch and connected it to a USB-C plug.

For the trigger mechanism I chose to use Adafruit’s KB 2040 electronic board due to it’s small form factor, and also that it works over USB-C / USB serial. I also chose to use the KB 2040 because the HyperPixel 4.0 uses all the GPIO pins of the Waveshare Nano A and USB-C / USB serial seemed like a more straightforward alternative. Alternatively I could have used I2C, via the HyperPixel 4.0, but I didn’t have enough time to go that direction before the convention. The trigger itself is an illuminated pushbutton switch also from Adafruit.

I’m no expert in 3D printing and I originally wanted the form factor to be smaller. But since the camera cable stuck out from the top, I needed to make extend the base.

So I designed and 3D printed a cap portion to hold it all together.

I even added a hinge and latch lock to for easy access.

For the software, I wanted something simple. I’m running python script to take the photos. One thing to note is that the camera does not have any autofocus (which is exactly how I wanted it). That meant I needed to see what I’m shooting before taking the photo. I added a preview in the software, so I could focus the lens, and then take the shot.

The desktop above shows the camera python script and the folder where the photos are saved. You can also see the Circuitpython mounted “disk” of the KB 2040 on the desktop. I’m also a space nerd so I chose a James Webb galaxy image as a backdrop to show off the beautiful Pimironi display. I included a fun logo and added a nice rectangle so I could easily see the program icons on the desktop too.

KAMPi in Action

KAMPi is so new, I haven’t been able to test it in the wild yet. But here are some raw unprocessed photos from my home test shots.

https://www.instagram.com/reel/DMR6OegOWSn/?utm_source=ig_web_copy_link&igsh=MzRlODBiNWFlZA==

More to come from Opensaucelive!*

Tomorrow is Opensaucelive 2025 and I thought what better place to test and share my build there. Wow, I’m so excited to share KAMPi with everyone at Opensauce. If you see me, please do say hello. I’ll also upload some photos from KAMPi at Opensauce below:

[*UPDATED July 20, 2025] See above sample photos I took at Opensaucelive 2025 using KAMPi. I chose the sharpest in focus images to share. Since it was my first time shooting with it, many of the photos came out blurry – which was exactly what I was expecting! I wanted KAMPi to emulate the feel of a film camera, capturing the moment. And KAMPi did just that. I’m also sure I’ll get better at taking photos with KAMPi with a litter more practice 🙂

[*UPDATED Sept 20, 2025] Updated the description of the KB 2040 to provide additional info on why I decided to use it over I2C.

Kampay (Cheers) for now!

Did you like my build? Would you like to learn more about it? Let me know at the comments below!

If you enjoyed reading this post please be sure to like, and follow us here at SKKAW.BLOG (IG: @skkaw) for more geek and pop-culture goodness.

#Adafruit #camera #CamPi #ComputeModule5 #digitalCamera #DIY #DIYCamera #DIYDigitalCamera #KAMPi #Opensauce #OpenSauceLive #PiCam #RaspberryPi #RaspberryPiCamera #RaspberryPiComputeModule5 #RaspberryPiComputeModule5Camera #SelfMade #selfMadeDigitalCamera #selfBuilt #SelfMade #Waveshare

Raspberry Pi Compute Module 5 vorgestellt
Der Raspberry Pi erweitert sein Portfolio mit dem Compute Module 5, einer kompakten Variante des Raspberry Pi 5. Das neue Modul richtet sich an Entwickler:innen und Unternehmen, die Embedded-Lösungen für industrielle oder kreative Projekte entwickeln.

Das Compute Mod
https://www.apfeltalk.de/magazin/news/raspberry-pi-compute-module-5-vorgestellt/
#News #Tellerrand #ARMCortexA76 #ComputeModule5 #EmbeddedSysteme #GPU #Industrie #iot #RaspberryPi

Raspberry Pi CM5 makes an appearance at a German trade fair ahead of official launch

The Raspberry Pi Compute Module 5 is an upcoming computer-on-a-module featuring a Broadcom BCM2712 processor, support for up to 16GB of RAM and 128GB of eMMC storage, and connectors that lets you connect the module to a carrier board or other devices to add ports and connectors.

Raspberry Pi hasn’t officially introduced the Raspberry Pi CM5 yet, but it looks like a pre-release version of the module is on display at the electronicaFair 2024 show in Germany this week.

A picture of the module shows that it has the same processor as the Raspberry Pi 5 single-board computer that was launched in 2023 and a physical design that looks a lot like the Raspberry Pi CM4. But it supports up to twice as much memory and four times more onboard storage than the previous-gen computer module and should deliver a significant performance boost thanks to a 2.4 GHz quad-core ARM Cortex-A76 processor (up from the 1.5 GHz quad-core ARM Cortex-A72 processor used in the Raspberry Pi 4 and CM4).

It looks like Raspberry PI will also offer an updated I/O board for the new model =, with two full-sized HDMI ports, two USB 3.0 Type-A ports, and an M.2 slot for PCIe NVMe storage.

There’s no word on how much the new module or carrier board will cost, or when it will be available. But after making a public appearance like this, it’s likely that we won’t have to wait long for an official announcement.

via Tom’s Hardware

#cm5 #computeModule5 #electronicafair #raspberryPi #raspberryPiCm5
