Parallel TDA7293 with OPA1655, further modified protection circuit

#diyaudio
#Audio
#diyamp
#diyamplifier

Parallel TDA7293 + OPA1611+ClassA

#diyaudio
#DiyAmp
#DIY
#Audio

New TDA7293-Amp Project. Two parallel TDA7293 on each side. 200W-Transfomer, Mundorf Mlytic

#DIYAUDIO
#audioamp
#diyamp
#TDA7293

Finished. Hybrid bass amp (valve preamp, IC power amp) plus 2x10 bass cabinet. The baffle is a found piece of oak 2.5in thick which makes the sound precise and responsive. Building this rig has been... character building... but it sounds great #bassguitar #diyamp #bass
Breadboarded the preamp stages of my bass amp with a 12AU7 valve, which I'm running at 9v to get some nice overdrive at high gain. The pot is a tone control and it works pretty well. I'll need to add a gain pot too or I'll just sound like Lemmy all the time #bassguitar #amplifiers #diyamp #electronics
