Raspberry Pi CM5 industrial computer features RS485/RS232/CAN Bus/DIO interfaces, dual Ethernet, optional 4G/5G cellular module

Waveshare IPCBOX-CM5 is an industrial-grade mini computer built around the Raspberry Pi CM5, featuring RS485, RS232, CAN Bus, and DI/DO terminal blocks, dual Ethernet, an M.2 socket for NVMe SSDs or AI accelerators, and a wide 7V to 36V DC power input. The system is compatible with all CM5 variants and integrates GbE and 2.5GbE ports, a 4K-capable HDMI video output, multiple USB 3.2/2.0 ports, and an M.2 B-Key slot plus a Nano-SIM card slot for 4G LTE/5G cellular modules. Other features include microSD card support for Raspberry Pi CM5 Lite models, a PWM fan header, a buzzer, an audio jack, an RTC battery header, and a speaker connector. Housed in an aluminum alloy case with heat-dissipation fins, the unit also supports DIN-rail and VESA mounting for industrial control, IoT gateways, smart factory systems, network appliances, and remote monitoring deployments. Waveshare IPCBOX-CM5 Specifications: Compatibility – Raspberry Pi Compute Module 5 (CM5
