Derick Rethans' BlogOriginal Post
In the last few weeks, I have been working through some bug reports for Xdebug, that resulted in the Xdebug 3.5.3 release.
These bug reports did not come solely from humans, but rather from a mix of humans using LLM assistant tools, focussing on security related problems, from two different sources and methodologies.
Although all of these issues where indeed bugs that I now have fixed, I don't think any of them can be classified even as having a low security impact.
But there was a whole host of other issues with these reports. The reports themselves can be unnaturally verbose — and also fairly alarmist using terms like "victim" and "attacker". The tests that were present in the reports were often minimal, and sometimes incomplete, and so were some of their suggested fixes.
The humans forwarding the reports took care not to flood the issue tracker with reports out of the blue, and reached out to me first. They've also been helpful discussing the reported issues.
The first four cases were reported by Ilia Alshanetsky, a long time, and recently returned, contributor to PHP.
The first report, #2421, deals with sending wrong option characters with commands through the DBGp protocol, that an IDE and Xdebug use to communicate.
Xdebug would allocate an array for 27 of these, representing the 26 lower case letters of the Latin alphabet, and the - character. What Xdebug did not do is to make sure the option letters were indeed in the range [a-z-], and would happily accept -@ or -\x00. This makes it possible to overwrite locations in memory.
The suggested patch was fine, but the test that went with it was very hard to read. It didn't use already exiting framework for testing the step debugger either — I had to add my own.
I also believe that this issue could as easily have been found by a fuzzer, which I added now as well. The fuzzer found the same problem in about five seconds, and luckily, nothing else either.
The second issue, #2422 complained that there was no limit in the debugger's code that reads commands from the network.
The patch was mostly fine, but the test was wholly cumbersome again — it didn't use the already existing testing framework either. It also picked a funnily large (arbitrary) limit of 64MB for DBGp commands, where 64KB would easily suffice — in most cases, 256 bytes would have been fine.
The third issue, #2423, argues that Xdebug shouldn't follow symlinks when creating profiling or trace files.
The patch was OK and trivial, but the test was again very hard to read making it hard to figure out what it as trying to do. It also did not make use of some existing helpers to skip tests. It came up with:
--SKIPIF-- <?php if (PHP_OS_FAMILY === 'Windows') die('skip: Linux-only symlink semantics'); ?>Instead of what is used everywhere else:
--SKIPIF-- <?php require __DIR__ . '/../utils.inc'; check_reqs('!win'); ?>The fourth and last issue through Ilia, #2424, deals with Xdebug's Control Socket functionality, where its parser would not handle empty or large command packets correctly. The LLM proposed patch fixed the symptoms, but not the actual cause of this issue.
The second set of reports were shared with me in a private gist by Volker, as part of the PHP Foundation's Ecosystem Security Team effort.
The first one was a duplicate of bug #2421. The test focussed on the Control Socket functionality instead of the Step Debugger, but the underlying issue and fix were the same.
The second issue I added as bug #2433. When you enable xdebug.collect_assignments with tracing, Xdebug needs to re-create the variable name from several opcodes in order to show this name in a readable way.
But the issue is not a real time problem, insofar this can only happen if you run PHP code on the command line through the -r option, xdebug.start_with_request is yes. For some reason, when PHP runs code through -r, the CLI binary does not generate EXT_STMT opcodes (Xdebug uses these for breaking during step-debugging), which would otherwise prevent the out-of-bound memory read from happening.
The LLM tool also hadn't realised that the third argument to the function responsible for reassembling the variable name was always NULL, and hence superfluous.
I addressed these both through the same commit, and added a test, which would not exhibit the problem in most situations either. It is still good to have the expected outcome documented.
Another report resulted in two issues in Xdebug's tracker. #2427 addresses an incorrect memory read if the xdebug.file_link_format setting ends with a lone %, and #2429, a similar report, but then for xdebug.trace_output_name.
Although the report mentioned three locations, the accompanying test only covered one of three situations where this was a problem: for trace file names, but not formatting link files through xdebug.file_link_format, nor profiling files.
The patch it suggested was also wrong, as it would remove the trailing % instead of keeping it. One of three locations where the trailing % was not handled, was internal only, and hence couldn't be triggered by making configuration errors.
The test that came with this report did not help me trying to show the problem. It relied on AddressSanitizer to show any problems, but I could not get that to happen. All the tests through this tool also provided tests that tested that the was present, and not what the correct result ought to be.
Luckily, using the Xdebug test suite with the valgrind tool showed the problem.
A further report, #2430 showed a problem if either an IDE through the step debugging protocol, or a developer directly, would request the contents of a "variable" named :::. The step debugger uses :: to indicate "all the static variables for this class", and following that up with a : isn't valid.
The fix was good, but I couldn't directly use the test case, as it tested for the broken behaviour. The test was fairly trivial to write as the reproduce case in the reported test case was correct.
And the last issue from the second list, #2431, again reinvented its own way for doing DBGp tests, and also tested that the behaviour was wrong, instead of a test to show that it now works.
Even with the code fixed, the new correct test would also surface another issue, as it would have resulted in Xdebug to open a directory as it was a file, and then fail.
: Although the LLM tools did find bugs, they were not particularly groundbreaking. Some of the bugs would also have been found by fuzzing, and used a lot less resources in that process.
Most of the crashes and potential security issues would only be a problem if an attacker didn't already have access to the machine that the code runs on itself, or have an IDE talking to Xdebug already.
If you have access to the machine, you can do worse without these bugs present. If you have client access to Xdebug through DBGp, you would have all the functionality that PHP provides, including reading all files on the file system and running code.
The generated test cases were generally hard to read, or incomplete. The patches that the models came up with were not always comprehensive, or correct. I also spent too much time getting AddressSanitizer to do anything, unsuccessfully.
I think I would have been as quick writing these patches and actual test cases myself, when provided with the issues' causes and the reasoning that was provided.
I don't think I'll be spending time trying to get these tools to work myself, but in the right hands with people that know what they're doing, they can find issues that needs to be addressed. But the value comes from the humans interpreting their results.
