Great example project of a complete machine design with open source software.
Forged in FreeCAD: LumenPnP, An Open Source Pick and Place Machine
https://blog.freecad.org/2024/04/12/forged-in-freecad-lumenpnp-an-open-source-pick-and-place-machine/ #FreeCAD #LumenPnP #Kicad #WireViz
Just noticed that WireViz (A documentation tool for electrical wiring/cables - https://github.com/wireviz/WireViz ) has recently released an update.
One of the new features let you mark connectors as being joined together, which should let me unbodge a couple of my existing diagrams.
Wochenrückblick, Ausgabe 24 (2024-03).
Diesmal mit WireViz (GraphViz für Verkabelungen 🤓), einem hypnotisierenden Blick auf die Bits des aktuellen Unix-Timestamps, Applite - dem macOS App Store für Homebrew Casks, noch mal llamafile (LLM für die Ausführung auf dem eigenen Rechner), dem BFG Repo-Cleaner und wie mir dieser helfen soll (BFG9000 kennt ihr auch noch?), Debugging-Tricks für die Browser Developer Tools, wieder Wildschweine im Garten und wie immer Techno.
#WireViz #GraphViz, #Timestamp #Y2K38 #Applite #llamafile #BFGRepoCleaner #BFG9000 #DevTools #Browser #WebDev #Debugging #Wildschwein #Techno
@melle ok, I found the output files in #wireviz
If you don't supply a -o output then the output files are in the same folder as the input file.
That makes sense, I guess it would be either there or the "Present Working Dir"
Thanks for a useful tool. Now I have to see how to handle a cable(wire) with more than 2 connectors.
This is becoming my rabbit hole for the day.
@melle thanks for the tip. I downloaded it and tried and it worked the 2nd time.
The trick is you have to specify an output even thou their doc say its optional.
wireviz -o fred /home/me/Downloads/wireViz/demo01.yml
You will get 5 files with name fred and different extension, one for each type of output(png,svg,html etc)
#wireviz #python #floss
