OpenTrafficMap ESP32-C5 C-ITS receiver board can help improve traffic efficiency using 802.11p V2X communication
The ESP32-C5 C-ITS receiver project is an open-source hardware board that gathers data over 802.11p V2X communication from nearby traffic lights, public transportation (buses, trams...), trucks, cars, motorcycles, and even pedestrians to display the results on online maps. It works using the ITS-G5 protocol built on top of 802.11p V2X (Vehicle-to-Everything), which requires a 5.9 GHz WiFi radio, and makes the ESP32-C5 an ideal candidate. The standard requires a C-ITS Station (ITS-S) found in vehicles (on-board units - OBU) or roadside units (RSU) handling both transmission and reception, and a receiver to handle incoming wireless signals, decode C-ITS (Cooperative Intelligent Transport Systems) messages, and feed the data into online maps like OpenTrafficMap (See screenshot below). ESP32-C5 C-ITX receiver specifications: Wireless module - ESP32-C5-WROOM-1 (ESP32-C5-WROOM-1-N16R8 or ESP32-C5-WROOM-1-N8R8) SoC – ESP32-C5 CPU Single-core 32-bit RISC-V processor @ up to 240 MHz Low-power RISC-V core @ 40 MHz acting as the main processor for
