Supersonic Jet Interaction

When supersonic jets get emitted into rarefied air, they behave differently than they do in regular atmospheric conditions. Here, researchers picture three different configurations these jets can take. In the top image, the jets are close enough together that they appear to merge into a narrow supersonic jet. In the middle image, the jets are not quite as close together. They merge but form what appears to be a subsonic wake. In the final image, the jets are far enough apart that they don’t merge, although they do appear to “lean in” toward one another. (Image credit: S. Lee et al.)

#2025gofm #flowVisualization #fluidDynamics #instability #jets #physics #science #supersonic

Jets From Impact

When a test tube of liquid hits a surface, the curvature of the meniscus focuses the rebounding fluid into a jet. In this video, researchers show some of the many variations they’ve explored on these experiments–from changing the depth of the fluid and the shape of the container, to changing the working fluid to honey or to dry grains. It’s a nice introduction to a fascinating phenomenon! (Video and image credit: H. Watanabe et al.; research credit: H. Watanabe et al. and K. Kobayashi et al.)

Animation showing how granular jets form in a test tube impact. #2025gofm #flowVisualization #fluidDynamics #jets #meniscus #physics #science #vibration #waterImpact

Liquid Pulleys and Gears

In mechanical systems, gears and pulleys transmit rotation from one location to another. Here, researchers explore a fluid dynamical version of such systems. The set-up consists of two rotors contained in a cylindrical corral filled with a water-glycerin mixture. One of the rotors is active, marked here with orange; the other (blue) one is passive, meaning that it can rotate due to the forces on it but it is not actively driven by a motor.

The three flow visualizations illustrate different configurations the rotors can take on, depending on their separation distance. In the top image, the rotors have a moderate separation distance and the passive one rotates opposite of the active one. That rotation direction is set by the high-shear flow on its inner side. If the rotors are close together (left image), they rotate in the same direction, aided by strong shear on the outside edge of the passive rotor; this mimics being linked with a belt. And, finally, if the rotors are widely separated, they also corotate, with the fluid in between acting like a virtual gear linking them. (Image credit: J. Smith et al.)

Research poster showing how an active and a passive rotor can be paired through hydrodynamic interactions. #2025gofm #flowVisualization #fluidDynamics #physics #science #viscousFlow

Plucking Droplets

A sudden breeze can pluck droplets hanging from a stem. Here, researchers recreate that phenomenon in the laboratory. With a close-up view and high-speed images, we can enjoy every detail of the detachment and break-up. As the wire pulls away, it drags a liquid sheet off the droplet. The thicker rims on either side of the sheet eventually collide, creating a jet that stretches, deforms, and, at last, breaks. (Video and image credit: D. Maity et al.)

Animation of two droplets getting plucked, one made of glycerin+water (left) and one of water (right). #2025gofm #droplets #flowVisualization #fluidDynamics #physics #science #surfaceTension #viscosity

Bouncing on a Wave

On a vibrating fluid, droplets can bounce and interact in complex ways. Here, researchers demonstrate some of the peculiar dynamics of these wave-guided droplets, showing how they can do things like pair up in waltzes. To keep the droplets from coalescing with one another, they perform their experiments in a pressurized chamber; the higher air pressure makes it harder for the air film between droplets to drain during a collision, making the droplets unable to coalesce. Under these conditions, the authors show that the droplet-wave system has quantum-like statistics. (Video and image credit: J. Clampett et al.)

#2025gofm #bouncingDroplets #coalescence #droplets #flowVisualization #fluidDynamics #hydrodynamicQuantumAnalogs #physics #pilotWaveHydrodynamics #quantumMechanics #science #vibration

“Sidewall Symphony”

Flow visualization is both an art and science in fluid dynamics. Here, researchers were interested in studying the separation bubble that forms over a backward-facing ramp–a shape that shows up, for example, on an aircraft. In these areas, the flow over the surface separates, leaving an unsteady, recirculating bubble.

That’s the flow that researchers are visualizing here. They’ve done so by adding tiny helium-filled soap bubbles to the flow. With bright lights illuminating the bubbles, each one leaves a streak in a photograph, showing where the bubble moved during the time the camera’s shutter was open. Although images like these are beautiful, they can also be analyzed by computers to extract the underlying flow that created the image. (Image and research credit: B. Steinfurth et al.; see also here)

#2025gofm #flowVisualization #fluidDynamics #fluidsAsArt #physics #science #turbulence

Schooling at Scale

Relatively simple visual and hydrodynamic signals are enough to make digital fish school in ways that resemble living ones. Here, researchers look at what happens when well-behaved schools of fish get too big. The researchers first demonstrate that their schools behave reasonably at one hundred members, either in a schooling configuration or a group milling around a central region.

At one thousand fish, the schools are still reasonably coherent and sensible. But at fifty thousand fish, the picture is drastically different. Neither schooling nor milling groups are able to remain together. They fracture and scatter into smaller groupings. (Video and image credit: H. Hang et al.)

#2025gofm #activeMatter #biology #collectiveMotion #fish #fluidDynamics #instability #numericalSimulation #physics #schooling #science

Bursting an Oobleck Bubble

When soap bubbles burst, the hole grows as an expanding circle. But not every fluid bursts this same way. Here, researchers let air rise through oobleck–a fluid made from cornstarch suspended in water–to form a bubble. In time, as with all bubbles, the oobleck bubble bursts. But–in keeping with oobleck’s solid-like properties–the film tears open and fractures. As it sinks back into the liquid, it wrinkles before it slowly relaxes back into fluid form. (Video and image credit: X. Zhang et al.)

#2025gofm #bubbles #fluidDynamics #oobleck #physics #science

Bursting Bubbles

When air bubbles rise through a liquid, they scavenge dust, viruses, microplastics, and other impurities as they go. Once at the surface, these contaminant-covered bubbles thin and burst, generating many tiny droplets that arc through the air above. You’re likely familiar with the sight and sensation from a glass of champagne or soda.

Here, researchers have stacked two sets of sequential images to illustrate this complicated flowscape. Under the surface, a trio of photos are stacked to show bubbles rising and gathering at the surface. In the air, the researchers have stacked thirty sequential images, which together trace out the parabolic arcs of droplets sprayed by the bursting bubbles. (Image credit: J. Do and B. Wang)

#2025gofm #bubbles #bursting #droplets #flowVisualization #fluidDynamics #physics #science

Bioconvection

Convection isn’t always driven by temperature. Here, researchers explore the convective patterns formed by Thiovulum bacteria. These bacteria are negatively buoyant, meaning they will sink if they aren’t swimming. They also have an asymmetric moment of inertia, so any flow moving past them tends to affect their swimming direction.

When let loose in a Hele-Shaw cell with a oxygen levels that decrease with depth, the bacteria create complex convection-like patterns. They swim slowly upward in wide, slow plumes and sink in denser, narrow plumes. In other areas, they form large-scale rotating vortices. (Video and image credit: O. Kodio et al.)

#2025gofm #bioconvection #biology #convection #flowVisualization #fluidDynamics #physics #science
