Jonas 3j14Feb 26
Cosmic Meow BackgroundFeb 26

> This design probably hits the record of simultaneous use of TI parts in a single device.
*looks inside*
> Figure 2-1. 100-kV Reference Voltage
It said high-voltage reference on the tin. I expected high-voltage, just not 100kV.

For those reading along from a safe distance: https://www.ti.com/lit/an/sbaa203b/sbaa203b.pdf

Jonas 3j14Feb 17
PhosFeb 17

We just released a new video on theory and experimentation with high speed high linearity analog optoisolator circuits, DC to 1MHz.

I feel it turned out pretty well, give it a watch!

https://youtu.be/0tC-rYfaZB8

Boosts appreciated!
#electronics #engineering #analog

Jonas 3j14Jan 19
Chaostreff TübingenJan 19

Hallo miteinander 👋

Der #ctt hat @anneroth eingeladen um über geschlechtsspezifische digitale Gewalt zu sprechen.

Komm doch vorbei und erzähl es deinen Freund:innen.

Dienstag 10.2. franz.k Reutlingen (Hbf)
Einlass 19:30
Beginn 20:00
Eintritt frei

https://www.franzk.net/buehne/10-02-2026-geschlechtsspezifische-digitale-gewalt-ein-vortrag-mit-anne-roth

Jonas 3j14Jan 14
GregJan 6
Crisp solderpaste 😋
Jonas 3j14Jan 2
Cosmic Meow BackgroundJan 2
first board of the year! (designed and ordered last year)
this is a bipolar analog bias supply for bread-board and also solder-on use.
this is, i think the third iteration of this circuit and i got tired of layouting it over and over again so now it’s a module.
It‘s wide-vin with a boost, an inverting buck-boost and a TPS7A39 LDO to have clean supplies.
Show threadJonas 3j14Dec 29
@LucasWerkmeister what is a qid? Or what do you mean by item ID?
Jonas 3j14Dec 21
@sad_electronics yes! I need this! Also good to look up common parts that are easy to source and have alternatives available
Show threadJonas 3j14Dec 13
of course the LEDs are also animated
Jonas 3j14Dec 13

they work! I'm now running rust on my earrings.

and battery life is much better than expected (more than 4h, depending on the brightness of the LEDs).

Jonas 3j14Oct 26

@sad_electronics wait, the USB ports are blue so I would expect it to be USB 3. Is that not standardized?

Out of curiosity, what vendor ID is reported when plugging this into a computer? I have no idea, does the chip already come with a vendor ID? Or do companies (in this case Hema) use their own when manufacturing devices on a commercial scale?
