Footing Transfers load from column to soil safely and prevents settlement.
Kalai
@kalaim
- 2 Followers
- 43 Following
- 4 Posts
Civil engineering isn't just about big ideas—it's about the small details that hold them together. 🏗️📐
Rebar detailing is where the load path meets the bar path. Get it wrong, and your beam is just expensive gravel.
Details matter.
#CivilEngineering #RebarDetailing #StructuralEngineering #ConcreteConstruction #EngineeringBasics
Rebar detailing: where theory meets the tie wire. 🧵🏗️
Wrong bend = field fix.
Wrong lap = structural risk.
Wrong spacing = no vibrator access.
Get it right on paper so they can get it right in the field.
#CivilEngineering #RebarDetailing #StructuralEngineering #Concrete
Rebar detailing is where structural engineering meets constructability. It’s not just about placing steel it’s about ensuring the forces visualized in the model can actually be built in the field
A good detailer balances:
📐 Code compliance (ACI 315, etc.)
🔗 Lap splices & development lengths
🛠️ Crane access & congestion solutions
Bad detailing = RFIs, delays, and cracks.
Good detailing = a foundation that performs.
Shoutout to all the detailers turning 2D lines into 3D reality. 🏗️
#civilengineer
A good detailer balances:
📐 Code compliance (ACI 315, etc.)
🔗 Lap splices & development lengths
🛠️ Crane access & congestion solutions
Bad detailing = RFIs, delays, and cracks.
Good detailing = a foundation that performs.
Shoutout to all the detailers turning 2D lines into 3D reality. 🏗️
#civilengineer
