SOT23-5 to DIP-8 Single Op Amp Adapter Boards

There are lots of single channel op amps available in DIP-8, but there aren't a huge amount of newer options. If you want something designed this century, SOT23-5 is a more common package. The problem is, single channel op amps in SOT23-5 and DIP-8 have completely different pinouts, so standard adpater boards, which preserve the SOT23 pinout, aren't ideally suited to the job.

https://blackthornworks.wordpress.com/2024/01/03/sot23-5-to-dip-8-single-op-amp-adapter-boards/

5 way superswitch wiring diagram for two humbuckers.
The two extra positions use one coil from each pickup and connect them in series. This is equivalent to a humbucker with the coils spread apart- you get humbucker-like tonality and output levels, but with a different flavour.

#guitar #guitarelectronics #guitarproject
