New Clock & Dividers are done!
Revisions include:
- A revised input section that can accept bipolar signals and slow edges using a base-shunted schmidt trigger.
(Can generate gates that correspond to suboctaves of an oscillator/audio source)
- Reduced ground impedance, and loop areas should reduce noise & emissions.
- Slightly reduced current consumption. (I don't have specific specs for this though - I need a current tester!)
-Output protection diodes now have lower junction capacitance.
-More local capacitive storage, for all the switching components.
And some coscmetic alterations!
