i looked at the rpgp codebase and it is very good code. incredibly small and the directory structure alone is remarkably effective
#[derive(Debug, Snafu)]
#[snafu(display("needed {}, remaining {}", needed, remaining))]
pub struct RemainingError {
pub needed: usize,
pub remaining: usize,
backtrace: Option<Backtrace>,
}

wrote a good amount of code like this for the zstd impl that stopped when i realized zstd was weird and bad

i'm gonna try to make the proof of concept for length extension now. i'm very confident i'm right
i have to generate their fucked up little format
you literally just generate blocks that have zero length
it's the most unnecessary thing https://amass.energy/rustdoc/yzx-unstable/yzx_core/frame/data/ ziv-lempel's bullshit already lets you do run-length shit. why are there TWO ways to encode a run-length block of the same byte
yzx_core::frame::data - Rust

Encoding of a Zstandard frame.

the problem with e.g. writing code that would analyze .tar.zsts in the wild is that the zstd format is brain destroying and offensively poorly documented
yann collet owes me 1 million dollars for being incredibly insecure and not writing up his "standard"
SequenceBehavior in yzx_core::frame::data::block - Rust

API documentation for the Rust `SequenceBehavior` enum in crate `yzx_core`.

there's never any actual offsets, sizes, block counts, id sets. the zip format has all of that shit. and google hates it

the idea is so basic it's literally:

  • split a .tar in two like a magician
  • read in an arbitrary byte stream from the user, encoded as 0-length RLE blocks
  • sandwich output
and there are two distinct ways to do this. have i mentioned i really despise this format
jarek duda's tANS is cool as shit though. yann collet is such a loser for repeatedly obfuscating it. it's one of those cool mathematical results that is not a magic bullet but solves a specific problem and i like that duda is interested in expanding the application to other areas of information theory. the blake3 paper also mentions compression and i think these both should absolutely be more closely allied
compression unfortunately still sucks bc everyone acts like they absolutely cannot wait or expend CPU time on something that will be decompressed 100x or 1000x more than it was compressed
god i really hate this format. i'm gonna do it the slightly less annoying way first. i really hope the annoying way (not creating a new frame but embedding it in the previous frame, again as 0-length RLE blocks) does not require a whole encoder. i'm gonna add a dependency for that shit

this is my enum for their block type header

#[inline(always)]
fn block_type(&self) -> BlockType {
match (self.0 & 0b110) >> 1 {
0 => BlockType::RawBlock,
1 => BlockType::RLEBlock,
2 => BlockType::CompressedBlock,
3 => BlockType::Reserved,
_ => unreachable!("block type is limited to two bits"),
}
}

two whole bits:

  • "raw": on its face: sure! not bad! if it doesn't compress well, don't compress it! we will discuss the flaw there in a moment
  • "RLE": the idea here is that you would have a massive run of a single byte. and like. ok. but that is also very much what the compression is supposed to handle for you already

the problem with prefix codes as i understand it now is that they require at least one bit to signal an output symbol (which is typically a byte--i also think this is incredibly important to parameterize). however prefix codes seem to be ideal in every other way (collet mentions performance)

and for extremely biased distributions i.e. ones that would benefit from less than one bit for some highly frequent output symbols, we have (actually a whole field here, but i like) duda's tANS. it's cute. it can be sized to a precise memory region. you follow the path of the blocks wherever they lead

i could cite yann collet on this here but i won't cause he doesn't. and i cited everyone here https://codeberg.org/cosmicexplorer/corporeal/src/branch/main/literature/README.md

corporeal/literature/README.md at main

corporeal - String library that uses corpus dictionaries to produce a more efficient encoding than UTF-8.

Codeberg.org

the compressed block is where it becomes clear zstd is Just Fucking Deflate Again: https://en.wikipedia.org/wiki/Deflate

BTYPE (next two bits): Block type

  • 00: No compression (sometimes called stored). Any bits up to the next byte boundary are ignored. The rest of the block consists of 16-bit LEN, 16-bit NLEN (one's complement of LEN), and LEN bytes of uncompressed data, i.e. up to 65,535 (216 − 1) bytes. Useful for incompressible data (e.g. high-entropy, random, or already compressed), adding minimal overhead (i.e. ~5 bytes per block).
    • 01: A static Huffman compressed block, using a pre-agreed Huffman tree defined in the RFC.
    • 10: A dynamic Huffman compressed block, complete with the Huffman table supplied.
    • 11: Reserved (error).

shameless shit. they even kept the reserved block

Deflate - Wikipedia

@hipsterelectron incredible
@astraleureka i forgot to mention the punchline which is that the one type of block that's not in DEFLATE (RLE block) is very specifically the one you can misuse
@astraleureka and the use case doesn't really make sense since RLE should either be a component of the compression scheme like ziv lempel or you should do compression across the whole file contents which is correct
@astraleureka billy mays here BUT WAIT, THERE'S MORE!

@astraleureka https://datatracker.ietf.org/doc/html/rfc9659

so in addition to saying "oh yeah skippable frames are for watermarking you can just remove them"

there's also these fucking zero-length fields everywhere

and this is a format that works extremely hard to save every goddamn bit in its fucked up headers

they tell you several times BE CAREFUL!!! SOMEONE MIGHT TELL YOU TO USE A BIG WINDOW! which is an indicator that the window size hint is either monopolistic orrrrrrrrrrrrrrr

so then the new update 9659 its ENTIRE fucking deal is saying BE CAREFUL!!!!! OF BIG WINDOWS!!!!!!

RFC 9659: Window Sizing for Zstandard Content Encoding

Deployments of Zstandard, or "zstd", can use different window sizes to limit memory usage during compression and decompression. Some browsers and user agents limit window sizes to mitigate memory usage concerns, thereby causing interoperability issues. This document updates the window size limit in RFC 8878 from a recommendation to a requirement in HTTP contexts.

IETF Datatracker
@astraleureka 0-size windows are the meta bro trust me
@hipsterelectron why the heck does this need to be a whole ass RFC
@astraleureka going into the public square and shouting the number zero, getting hauled away. medieval catholic church cyberpunk
