PolykitNov 28

A first batch of my Eurorack Clock Divider is now available as a PCB or DIY kit!
This handy utility module takes an incoming clock signal and divides it all the way down to 1/64.

If you’re curious about the details or want to see the schematics, check out the full blog post here:
https://polykit.rocks/eurorack-clock-divider-module-modular-synth-diy

#eurorack #synthesizer #synthdiy #clock #clockdivider #divider #pcb #kit #modular

Clock Divider

DIY Eurorack clock divider module. Generate rhythmic divisions for modular synths with an easy-to-build PCB and reliable timing performance.

POLYKIT SYNTH DIY
Show threadPolykitNov 14
The blog post on the Eurorack clock divider is ready! Find more details and the schematics at https://polykit.rocks/eurorack-clock-divider-module-modular-synth-diy #eurorack #synthdiy #synth #clockdivider #clock #cmos
PolykitOct 7
My next module is on the horizon: a clock divider based on the 4024 CMOS binary counter to accompany my sequencer. It's an utility module to break down a given clock signal to drive another sequencer, drums or similar. More on this soon!
#eurorack #synthdiy #synth #clockdivider #clock #cmos
