In the series: Electronics reflect life.
Circuit Board Philosophy, posted in Facebook group I take Pictures of Electronic Parts, by Calvin Nourse.

#electronics #circuitart #circuitboards #mastodonart #mastoart

The very awesome Chernobylizer.
From the Isn'tses, aka Lisa McKendrick and Tim Drage.

https://isntses.etsy.com

#circuitart #cities #synthesizer #noise

Logic puzzle 101: You got a strange message that does not make any sense. Can you decypher it with the following logic puzzle?

https://luckyresistor.me/2023/02/02/logic-gates-puzzle-101/

#puzzle #logic #gate #flipflop #xor #xnor #dlatch #lfsr #circuitart #circuit

Do you know the digital circuit puzzles? I just cross-linked them as interestingly many people only know one of the four available.

The idea for these puzzles came to me, when I redraw circuits because the ones generated by the EDS looked horrible. It is somehow, combining functionality with art.

There are hints, explanations and link to the other three puzzles here: https://luckyresistor.me/2021/04/29/logic-gates-puzzle-1/

#puzzle #circuitart #circuit #logic #gates

Labyrinthian Circuit Sculpture Evokes Moods With Sound and Light

In a famous letter penned by Victorian era author Oscar Wilde, he wrote:

_" Art is useless because its aim is simply to create a mood. It is not meant to instruct, or to influence action in any way. It is superbly sterile, and the note of its pleasure is sterility." _

We can't help but wonder if [Eirik Brandal] was evoking such Wilde thoughts when he wrote to tell us about ddrysfeöd, an electronic sound and light sculpture which he called "uselessly applied electronics." Given the mood created by the video below the break, we have to agree that it is indeed quite artful. But if it serves a purpose to inspire and cause wonderment, is it really useless? Let the philosophers philosophize. On to the hack!

[Eirik] was himself inspired by mazes such as those found in children's activity books and magazines whose goal is to keep a child ~~busy~~ challenged by drawing a solid line from start to finish. With these in mind, [Eirik] constructed ddrysfeöd as an intricate entanglement of electronics, metal, clear and mirrored acrylic, and plated steel, all flung into a three dimensional vortex.

ddrysfeöd is at home evoking moods in the light as well as the dark.

LED's of red and white oscillate in time with each other. Orchestrating the multimedia symphony is an ESP32, with one core relegated to dealing with the mundane functions of the sculpture while the other waves its electronic wand to keep the ensemble suitably arranged. LED's are bored into the base, and the acrylic is sanded on the edges to diffuse the supplied light. The electronics run on the usual +5 V, but a +12 V power supply gives volume to the LM380 audio amplifier. We also appreciated that [Eirik] expanded his skills on this project by using Sketchup to plan out the project, even printing the patterns for cutting and drilling the acrylic glass.

If [Eirik]'s build style looks familiar, it may be because you've seen it here on Hackaday's Circuit Sculpture Contest, where some of his work was named Most Beautiful. You can also feast your eyes on a BEAM bot inspired pummer in the shape of a satellite. And remember, if you run across something that presses your buttons, let us know via the Tip Line!

#art #circuitart #circuitsculpture #esp32 #lm380
