Axiomtek PICO570 – An Intel Core Ultra Meteor Lake Pico-ITX SBC with DDR5-5600 SO-DIMM memory, HDMI 2.1 up to 4Kp120
Axiomtek has recently introduced the PICO570, a high-performance Pico-ITX SBC built around Intel Core Ultra (Series 1) Meteor Lake-U processors. Measuring just 100 x 72 mm, this ultra-compact board with its 11 TOPS NPU is designed for edge AI applications. The PICO570 board is very similar to the AAEON PICO-MTU4 Pico-ITX SBC, but it features a physical 262-pin DDR5 SO-DIMM slot that allows users to upgrade or replace the RAM instead of solder-on LPDDR5 memory, and features an HDMI 2.1 supporting up to 4K resolution at 120Hz. The SBC also features an RS-232/422/485 serial interface, two USB 3.0 ports, and a dedicated SMBus connector for system management. With an operating temperature range of -20°C to +60°C, a watchdog timer, hardware monitoring, and a 12V DC input, it can be used for AI inference nodes, automation controllers, medical systems, and intelligent infrastructure. Axiomtek PICO570 specifications: Meteor Lake-U SoC (one of the other)
Beelink EX Mate Pro – A multi-function USB4 v2 80 Gbps dock with 2.5GbE, M.2 sockets, 140W charger, voice communication system, and more
Beelink EX Mate Pro is a multi-function USB4 v2 (80 Gbps) dock featuring four PCIe Gen4 sockets for M.2 SSDs, integrating a 140W charger with 96W USB PD charging for a laptop or mini PC, 2.5GbE networking, HDMI and USB4 video output, and a built-in quad-microphone array and speaker for voice interaction. Other features include a second 15W PD USB4 v2 port to connect peripherals like an external GPU (eGPU) or display, Bluetooth connectivity to convert the dock into a wireless speaker, USB 3.0 and USB 2.0 host ports, and buttons for volume control, microphone mute, etc... Beelink EX Mate Pro specifications: Storage - 4x M.2 PCIe Gen4 x1 sockets for NVMe SSDs Video Output HDMI port up to 4Kp60 USB4 v2 port Up to two independent displays Audio Speaker Quad-mic array with 5-meter range connected to B1 AI noise-cancellation chip (likely referring to Alif Semi Balleto B1) Bluetooth speaker
In our Supermicro SYS-112D-40C-FN8P review, we see how this system leverages the Intel Xeon 6 SoC (Granite Rapids-D) to provide 8x 25GbE
#25GbE #Intel #Supermicro #Xeon6 #Xeon6SoCSupermicro SYS-112D-40C-FN8P Review A 40 Core Intel Xeon 6 SoC Server with 8x 25GbE
Supermicro SYS-112D-40C-FN8P Review A 40 Core Intel Xeon 6 SoC Server with 8x 25GbE
In our Supermicro SYS-112D-40C-FN8P review, we see how this system leverages the Intel Xeon 6 SoC (Granite Rapids-D) to provide 8x 25GbE
Intel Core Ultra X7 358H-powered open robotics development system targets humanoid robots and autonomous vehicles
AAEON CEXD-INTRBL is an "open robotics development system" powered by a 16-core, 180 TOPS Intel Core Ultra X7 Processor 358H (Panther Lake) SoC and designed for the development of AI-enhanced humanoid robots and autonomous vehicle platforms. The Edge AI computer features four 2.5GbE ports with support for IEEE1588 PTP (Precision Time Protocol), two FAKRA connectors for up to eight GMSL2 cameras, four USB 3.2 Type-C ports, two USB 2.0 ports, a CAN Bus connector, and a 40-pin HAT connector with 22 GPIOs. AAEON CEXD-INTRBL specifications: SoC - Intel Core Ultra X7 358H CPU - 16-core (4P + 8E + 4LPE) Panther Lake processor @ up to 4.8 GHz Cache - 18 MB Smart Cache GPU - 12-core Intel Arc B390 GPU @ up to 2.5 GHz (122 TOPS) AI accelerator - 50 TOPS; CPU + GPU + NPU combined: 180 TOPS PBP - 25 Watts System Memory - Up to
Feature-rich Raspberry Pi CM5 carrier board offers dual Ethernet, quad RS485, 4G LTE/5G connectivity, and more
Waveshare CM5-ETH-RS485-4G-BASE Raspberry Pi CM5 carrier board offers plenty of features such as GbE and 2.5GbE RJ45 jacks, optional 4G LTE/5G connectivity, terminal blocks for RS485, relay, and digital outputs, and more. The board also features a 4K-capable HDMI output, an M.2 Key-M socket for an NVMe SSD or AI accelerator, two MIPI DSI/CSI connectors, ten status and user LEDs, and a wide 7-36V DC power input. Waveshare CM5-ETH-RS485-4G-BASE specifications: Supported system-on-modules - All Raspberry Pi Compute Module 5 variants with up to 16GB RAM, 64GB eMMC flash, Wireless Storage Optional NVMe SSD via M.2 Key-M socket MicroSD card socket for Compute Module 5 Lite only Video Output HDMI 2.0 port up to 4K resolution 2x MIPI DSI connectors (multiplexed with MIPI CSI) Camera I/F - 2x MIPI CSI connectors (multiplexed with MIPI DSI) Networking Gigabit Ethernet RJ45 port 2.5GbE RJ45 port Optional WiFi 5 and Bluetooth 5.2 on Raspberry
Advantech MIO-5356 – An industrial 3.5-inch SBC based on Intel Core Series 3 “Wildcat Lake” SoC
Advantech MIO-5356 is the very first hardware platform based on the upcoming Intel Core Series 3 (Core 300) "Wildcat Lake" SoC we've seen. It's a 3.5-inch SBC designed for industrial applications and powered by up to the Intel Core 7 350 hexa-core processor. The fanless board supports up to 64GB DDR5 memory, NVMe SSD storage, up to three independent displays via USB-C, HDMI, and LVDS interface, 2.5GbE and GbE networking with TSN and OOB management, and WiFi, Bluetooth, and Cellular connectivity via M.2 sockets. It also features audio connectors, six USB interfaces, RS232/RS485 and CAN Bus interfaces, and more. Advantech MIO-5356 specifications: Wildcat Lake SoC (one or the other) Intel Core 3 305 hexa-core CPU with 2x P cores @ 1.5 GHz / 4.4 GHz (Turbo) and 4x LPE cores, 16x EU Intel graphics @ 2.3 GHz; TDP: 15W Intel Core 5 320 hexa-core CPU with 2x P cores @
TerraMaster F2-425 Plus NAS review – Part 2: Configuration, benchmarks, and AI-enhanced media storage
I received the TerraMaster F2-425 Plus 3+2 Hybrid NAS for review last month, and after checking out the hardware in the first part of the review, I've finally had time to test the Intel N150 NAS. After installing two 4TB SATA drives and an M.2 NVMe SSD, I'll report my experience setting up the system with the TNAS Android app, before running some benchmarks, and testing features like photo backup with AI search capabilities. Hard drive installation I already had an old, but little-used, 4TB HGST SATA drive, and I bought a "new" 4TB SATA drive online for a pretty good deal (2979 THB or a little over $90 US). It turns out the HPE MB4000GVY2K drive I got was refurbished, having been manufactured in 2017. However, it's an enterprise-grade drive, and the TNAS app reports it has been used "only" for 2,517 hours, so I don't feel too bad
Thin Raspberry Pi CM5 fanless mini PC offers HDMI video output, 2.5GbE + GbE, dual USB, M.2 Key-M socket
Waveshare "Gigabit / 2.5G Dual Ethernet Mini-Computer (B)" is a thin Raspberry Pi CM5 fanless mini PC with a 4K HDMI video output, 2.5GbE and Gigabit Ethernet RJ45 jacks, two USB ports, a microSD card slot, and USB-C power. Internally, it features an M.2 Key-M socket for a 2230/2242/2280 NVMe SSD or AI accelerator, two MIPI DSI/CSI connectors for cameras or displays, and a 40-pin GPIO header. The flat cables for the MIPI devices can be passed through an opening under the HDMI and USB 2.0 ports of the metal case, and the GPIO headers are also accessible externally through a small cover under the enclosure. Gigabit / 2.5G Dual Ethernet Mini-Computer (B) specifications: Main board - CM5-DUAL-ETH-BASE-B Supported SoMs - Raspberry Pi CM5 or CM5 Lite (and potentially other electrically compatible modules like the Banana Pi BPI-CM5 Pro, Radxa CM5, and Orange Pi CM5, but it's not been tested
Industrial Wi-Fi 7 access point with redundant 12V – 48V DC inputs targets autonomous systems
Advantech EKI-6333BE-4GD is a tri-band Wi-Fi 7 industrial-grade access point designed for autonomous systems with support for redundant 12V - 48V DC inputs and a -40°C to 75°C operating temperature range. The access point delivers up to 5.8 Gbps throughput over Wi-Fi 7, features four 2.5GbE RJ45 ports, and the Taiwanese company also highlights compliance with IEC 62443 industrial cybersecurity standards and CE RED (Radio Equipment Directive) regulations, as well as support for WPA3 authentication and encrypted SNMP communication. Advantech EKI-6333BE-4GD specifications: SoC / Memory / Storage - TBD Wireless Compatible with IEEE 802.11 a/b/g/n/ac/ax/be standard WiFi 7 bands and maximum speeds 2.4 GHz up to 700 Mbps 5 GHz up to 2,900 Mbps 6 GHz up to 5,800 Mbps Operation modes - Access Point, Client, Repeater Highlighted features - Multi-Link Operation (MLO), Wi-Fi Multimedia (WMM), Preamble Puncturing Security - WEP, WPA/WPA2/WPA3-Personal, WPA/WPA2/WPA3-Enterprise Up to 6x antennas; 2x2x2 MU-MIMO Ethernet
Turris Omnia NG Wired dual 10GbE, quad 2.5GbE router drops Wi-Fi for cost savings
Not everybody needs Wi-Fi in their router. That's why Turris has now introduced the Omnia NG Wired dual 10GbE, quad 2.5GbE router without built-in Wi-Fi 7 connectivity to reduce costs. The specifications are the same as those of the earlier Turris Omnia NG Wi-Fi 7 router introduced last November, and it still features two 10 Gbps Ethernet SFP+ cages and four 2.5GbE RJ45 ports, but Wi-Fi 7 (and 5G cellular) connectivity is optional. Turris Omnia NG Wired (RTROM04-NGW) specifications: SoC – Qualcomm IPQ9574 (Networking Pro 820 Platform) quad-core Arm Cortex-A73 processor @ 2.2GHz Memory – 2 GB RAM Storage 8 GB eMMC storage M.2 socket for NVMe SSD Display – 240 × 240 px IPS color display Networking 2x 10 Gbps Ethernet SFP+ cages (WAN/LAN) 4x 2.5GbE RJ45 ports Optional WiFi 7 via upgrade kit Optional 4G LTE/5G cellular connectivity via mini PCIe slot and 2x SIM slots USB –
