The thread about the Calton Hill Naval Telegraph and the Forth coast’s Napoleonic communication system

Edinburgh’s City Art Centre shared this wonderful 1797 painting by George Walker this morning (July 11th 2023), showing the east of the old city as viewed from the vicinity of St. Anthony’s Chapel in Holyrood Park. This was an extremely popular viewpoint for 18th and 19th century artists and there are any numbers of etchings, watercolours and prints of this vista, making it a good record of the changes in the city over this time period.

This image of course poses the question: “what on earth is that enormous mast on the Calton Hill?!“

Well then, what on earth is that enormous mast on the Calton Hill? The answer is that this was a telegraph. No, not an electric or wireless telegraph, but a naval flagstaff for communication with ships in Leith Roads during the period of the French Revolutionary & Napoleonic Wars of the late 18th and early 19th centuries. The word telegraph of course long predates more modern uses and literally means “writing from a distance” and that’s exactly what a systems such as this could do; as and when daylight and the ambient visibility allowed, the mast could communicate by coded messages transmitted by hoisting various combinations of flags and marker balls up the staff.

The telegraph pole is clearly marked on John Ainslie’s 1804 map of the City:

And we can also very clearly see it in an advertising print for one of Robert Barker’s panoramas from 1806 that was exhibited in Leicester Square in London. His first panorama of this view, from 1792, does not show the mast in place.

An earlier print – also in the collection of the city – shows a similar scene to that of George Walker’s painting, however as the Bridewell – Robert Adam’s prison on the lower slopes of the Calton Hill – is missing from this scene it suggests that this is prior to 1795 and therefore that the mast pre-dates the installation of the Admiralty’s signal telegraph chain. The mast is absent in a plan of the city by James Watson and Thomas Brown dated 1793, suggesting it was erected between those dates. A chain of very similar telegraphs had been installed around the Channel Islands in 1792.

This Calton Hill signal post was at the western end of a telegraph chain that stretched between Edinburgh and St. Abbs Head, to forewarn of any French incursions into the Firth of Forth (bear in mind that in 1779, a small American squadron under John Paul Jones had tried just that) and allow the reporting of shipping traffic in and out of the Forth back to the Admiralty in Leith (formally the Commander-in-Chief at Leith and on the Coast of Scotland) . Interception and boarding parties could then be sent out to any unexpected or unknown vessels. This signal chain was apparently constructed in 1801, so would have been an addition to the pre-existing Calton Hill flagstaff. It is likely that the mast was first erected for communicating with ships anchored in the Leith Roads out in the Forth, at this time an important forming-up point for naval convoys.

With thanks to Chris Wright for his assistance in finding a copy of the relevant paper, I have plotted the Forth & East Coast flag telegraph chain onto a map (below). The 8 stations spanned 41 miles of coast from St. Abb’s Head in the east to Calton Hill in the west, for the Admiralty HQ in Leith. Messages that would otherwise take the best part of a day to carry could be transmitted (weather dependent) to and from Edinburgh and Leith in a matter of minutes.

Each station was manned by a lieutenant on half pay, a petty officer or midshipman plus as his deputy and two men. All to have been classed as “unfit for sea service”, meaning they were too old, young, or injured. The structures were hastily constructed and temporary, built largely from timber with canvas for roofing and little remains apart from perimeter walls to keep the sheep out or some levelled platforms for the signal staff and support guys. The wooden huts were painted with a mix of tar, ochre and sand. Life must have been dull, cold and uncomfortable.

For communication purposes, each telegraph was provided with 1 x large red signal flag (18 breadths x 7 yards size), 1 x large blue pennant (5 breaths x 50 yards size) and 4 x hollow canvas signalling balls, painted black (43″ diameter). A system of coded signals used combinations of the red flag, blue pennant and a certain number of balls. For instance the blue pennant plus 3 balls = “Enemy landing to the west“. The below diagram for the Port of Leith flag signals in the 1860s, shows how with just 3 flags and 2 balls, it was possible to unambiguously communicate the numbers 10 – 26 (and the halves in-between). Now make those depth numbers signals in a code book, and you’ve got yourself a telegraphic communication system.

Each station was provided with an inventory that included:

• 163 yards of roofing canvas
• A 30 foot flagstaff
• A 50 foot topmast for the staff
• 100 fathoms of 1.5 inch and 77 fathoms of 2.5 inch rope
• officer’s bath stove
• fire grate for the men’s quarters
• 6 chairs, 2 tables

Four chaldrons of coal (about 5.25 m3), £3 of candles and £1 of stationary were allowed per annum. It wasn’t until 1803 that the Admiralty made an allowance for 1 x cot bed (for the officer) and 3 x hammocks (for the men), and only upon written application. I have also inferred that the officer may not have lived permanently on site as he was given a travel allowance. The illustrations below, made by Royal Engineer Captain William Smith, show the telegraph station at Malin Head in Ireland in 1804. The flagstaffs and cabins would have been similar on the East Coast of Scotland.

Exceptions exist however. The stations at St. Abbs, Dowlaw and North Berwick seem to have been more substantially built from the local stone, perhaps due to their isolation or exposure? Good remains of the stone buildings remain on North Berwick Law above the town.

In case there was any doubt it was a military structure, rather than a shepherd’s bothy, one of the stones has been neatly inscribed with the cipher “G. R.”

And a section of flag staff (quite remarkably, if it’s original) remained in situ during the archaeological site survey in 2018!

I can find almost no mentions of the East Coast telegraph being used in the newspapers. The earliest is in the London Oracle on 26th October 1798, which records a scare that French warships were in the Forth when two friendly Russian warships did not give the correct signals and in consequence “the signal post on the Calton Hill was at work most part of the day“. A decade later in 1808 the Caledonian Mercury reported that the St. Abb’s Head station sent a message to Edinburgh that the damaged merchant ship Cygnet had drifted inshore there. An 1802 aquatint shows that the mast was still in place at that time:

Plans of the city include it up to 1809, but construction of the Nelson Monument from 1807 onwards soon made the flagstaff surplus to requirements – however the below illustration below by John Harden clearly shows the Monument in place where the flagstaff once stood but also shows the flagstaff standing to the east of it. This suggests that the staff was moved to an alternative location while the monument was still under construction.

The Monument was designed to effectively be a 160 foot tall flagstaff in its own right, to act as a signal station, with accommodation for the signallers, the officer in the tower itself and four injured seamen pensioners in the building at its base. It was intended that the duties of the occupants would include hoisting news of British naval victories and celebrating past triumphs on their anniversaries. For the latter purposes, flags bearing the names of these events were to have been provided.

The design of the monument by Robert Burn is said to be inspired by Nelson’s folding telescope. You have to admit that it was a big improvement on the obelisk style from an earlier draft by Alexander Nasmyth that had been rejected as too expensive.
