i've developed a lasting obsession with current load-balancing #electronics #diy

small VBUS proxy, to help with USB-powered devices profiling. here's the blueprint in case of need: https://codeberg.org/filipmnowak/usb2_vbus_proxy #diy #electronics

i've made alternative cover for "unstable orbits in the space of lies" short sf story; just kidding. i was looking for a way to map #multimeter switch states to pcb connections using #gimp, by tweaking transparency and colors.

just by looking at noodles, i know it's a #caturday 🤗

i was looking for a cost effective and safe ac source. i ended up getting enclosed variable transformer, from a fairly reputable brand - as playing with mains is no joke. according to common opinion, variacs are not that susceptible to inrush current - so no blown fuses etc. well, it seems opinion is not correct. a soft starter would be a nice addition to it. 1/2 #ee

let's make it early #caturday: inspector noodles supervises coffee machine fixing:

🤷 #ivoidwarranties

in unlikely case someone needs (yet another) sot-23-5 to dip board blueprint. this one is tweaked towards opamps and voltage regulators. https://codeberg.org/filipmnowak/sot-25-3_to_dip

#texasinstruments #lm338 voltage regulator feels magical. i was pushing it a bit, as radiator is 2-5w rated. #electronics #diy

don't judge, i did it for science! ;)
