#phonecamera #linuxphone #librem5 Librem 5 camera/kernel can do three possible resolutions, ~1024x768 @ ~24fps, ~2048x.. @ ~31 fps and ~4096x.. @ ~15fps. Debayering is actually easier and better quality if we downscale at the same time, and that allows best framerate, so we do that (2048x.. resolution).
ARM has problems with cache coherency w.r.t. DMA, and kernel solution is to simply disable cache on DMAbufs for userspace, which means accessing video data is 10x slower than it should be on the CPU. Which means debayering on GPU is attractive, and that's what we do. (gold.frag). GPU can do more image signal processing functions easily, too, so we do some of that.
Unfortunately, we hit the same uncached memory problem at the GPU output. So we use separate thread to copy. All this unfortunately does not fit on one core, so we need two threads, one controlling GPU debayer on frame n+1, while the other one copies video data from frame n. (heart.c). We save resulting RGBA data to ramdisk. This all costs maybe 80% of one core.
From there, Python scripts can pick them up:
ucam.py displaying the viewfinder and
mpegize.py handling the video encoding via gstreamer. There's basically 0% cpu left, but I can encode ~1024x.. video. Unfortunately that's without audio and with viewfinder at 1fps. Plus, combination of C + Python is great for prototyping, but may not be that great for performance.
Code is here:
https://gitlab.com/tui/tui/-/tree/master/icam?ref_type=heads .
At this point I'd like viewfinder functionality merged into the rest of GPU processing. Ideally, I'd like to have a bitmap with GUI elements, combine it with scaled RGBA data, and rendering it to screen. I know SDL and Gtk, SDL looked like better match, but I could not get SDL and GPU debayering to work in single process (template SDL code is here
https://gitlab.com/tui/debayer-gpu/-/blob/master/sdl/main.c?ref_type=heads ).
If you can integrate main.c and heart.c, that would be welcome. If you have example code that combines SDL with processing on GPU, that would be nice, too. If you know someone who can do GPU/SDL, boost would not be bad, I guess.
