Kết nối Wafer (wafer connection) là phương thức đặt van giữa hai mặt bích và cố định bằng bu lông xuyên qua. Nhờ không cần thân bích riêng, hệ thống ống ngắn gọn hơn và lắp đặt đơn giản hơn. Kiểu kết nối này thường dùng cho van bướm, van kiểm tra, van dao, van bi wafer. Để tìm hiểu kỹ hơn về ưu điểm, quy trình lắp đặt và các lưu ý trong chọn lựa van wafer, đọc bài viết chi tiết tại: https://tuanhungphatvalve.com/wafer-la-gi/
