Mastodawn

#[no_mangle(all)] entity my_code( clk: clock, rst: bool, px: int<32>, py: int<32>, hsync: bool, vsync: bool, col: int<32>, row: int<32>, char: inv &int<32>, foreground_color: inv &uint<24>, background_color: inv &uint<24>, uart_data: inv &uint<8>, uart_ready: bool, uart_valid: inv bool, ) { set char = &87; set foreground_color = &0xFFFFFFu24; set background_color = &0xFF7AFFu24; set uart_data = &0x00; set uart_valid = &false; }

Success!

UART Output

UtilizationCellUsedAvailableUsageDCCA2563.6%EHXPLLL1250.0%TRELLIS_COMB417242881.7%TRELLIS_FF128242880.5%TRELLIS_IO111975.6%
TimingClockAchievedConstraint$glbnet$clkp130.92 MHz25 MHz$glbnet$clkt374.53 MHz250 MHz
Code

#[no_mangle(all)]
entity my_code(
    clk: clock,
    rst: bool,
    px: int<32>,
    py: int<32>,
    hsync: bool,
    vsync: bool,
    col: int<32>,
    row: int<32>,
    char: inv &int<32>,
    foreground_color: inv &uint<24>,
    background_color: inv &uint<24>,
    uart_data: inv &uint<8>,
    uart_ready: bool,
    uart_valid: inv bool,
) {
    set char = &87;
    set foreground_color = &0xFFFFFFu24;
    set background_color = &0xFF7AFFu24;
    set uart_data = &0x00;
    set uart_valid = &false;
}

#FPGA #Icepi-Zero #HDL #Spade

Y⃒̸̷̝̜̙ͥͥͥngmar May 22

Bought the last pointy spade from the store.

I have about 5 old spades but they all seem to be made in the bendy spade factory.

Lets hope this one is a bit tougher. Its an exact copy of the Fiskars one but only costs 1/5th.

I held them next to each other to see if the Fiskars was maybe thicker steel or heavier or maybe made of titanium. Not the case. Probably just marketing reinforced for those who want to believe. 🤷

#Tools #Gardening #Spade #Hervin #Fiskars

JCM May 22

@[email protected]

Yaaaaay, Spade support in @icepi-zero-bot is back! :D

RE: https://wafrn.jcm.re/fediverse/post/90adf5c7-ddcf-4ee2-8f5a-7e727a835640
#fedibot #Spade #FPGA #HDL

Icepi Zero Bot May 22

@[email protected]

@[email protected] asked

#[no_mangle(all)] entity my_code( clk: clock, rst: bool, px: int<32>, py: int<32>, hsync: bool, vsync: bool, col: int<32>, row: int<32>, char: inv &int<32>, foreground_color: inv &uint<24>, background_color: inv &uint<24>, ) { set char = &0; set foreground_color = &0xFFFFFFu24; set background_color = &0xFF7AFFu24; }

Success!

UART Output

UtilizationCellUsedAvailableUsageDCCA2563.6%EHXPLLL1250.0%TRELLIS_COMB359242881.5%TRELLIS_FF113242880.5%TRELLIS_IO101975.1%
TimingClockAchievedConstraint$glbnet$clkp140.29 MHz25 MHz$glbnet$clkt363.5 MHz250 MHz
Code

#[no_mangle(all)]
entity my_code(
    clk: clock,
    rst: bool,
    px: int<32>,
    py: int<32>,
    hsync: bool,
    vsync: bool,
    col: int<32>,
    row: int<32>,
    char: inv &int<32>,
    foreground_color: inv &uint<24>,
    background_color: inv &uint<24>,
) {
    set char = &0;
    set foreground_color = &0xFFFFFFu24;
    set background_color = &0xFF7AFFu24;
}

#FPGA #Icepi-Zero #HDL #Spade

wenzellabs May 15

my upcoming FPGA dev board "#bare_metal".

most tests are done, most changes and bugfixes are in this V2. not sure when I got time for a "tapeout" ;)

- 16x8 SPI based RGB LED display
- single PMOD interface
- OK button and D-pad
- USB bootloader
- 3 user bitstreams by default, extendable to dozens
- LiPo battery with protection and management
- comes with a PCB stand
- PCB stand comes with pinout tables

#FPGA #bare_metal #yosys #nextpnr #verilog #amaranth #spade #HDL #nametag

aitan Feb 16

“Ma io sono un uomo che preferisce #perdere piuttosto che #vincere con metodi #sleali e spietati. Grave colpa da parte mia, lo so! E il bello è che ho la sfacciataggine di difendere tale colpa, di considerarla quasi una virtù..."

Dalle pagine corsare di #Pasolini, che era uno a cui piaceva giocare a #pallone.

[No ai #bastoni, sì alle coppe e ai denari.
(Delle #spade,poi, non se ne dovrebbe neanche parlare.)]

avikantz Feb 12

Jack of all trades

80D, 26mm, F11, 10s

#playingcards #cardgame #jack #spade #heart #club #diamong #gold #lightpainting #lightpaintingphotography #longexposurephotography #macro #stilllife #objects #photography

JCM Jan 28

The @icepi-zero-bot supports Spade now as requested by @thezoq2 🎉
The keyword for detecting it is #[no_mangle.

Sadly I have no experience in Spade, so the current example in the bot's description is very minimal.
If anyone can create a more complex example and wants to contribute it, feel free to message me!

RE: https://wafrn.jcm.re/fediverse/post/c349a0ba-6667-4406-b11f-b95e860f2822
#FPGA #Icepi-Zero #Spade #Spade-HDL #bot #fedibot
