fluencyCAD current state

https://peer.raise-uav.com/videos/watch/70e4d8a0-0722-41e0-bf9e-a53d378e143b

fluencyCAD in the wilds

I just mirrored the fluencyCAD repository to the open section form internal so anyone who is interested have a look. Don´t expect super clean stuff though. It´s in a very early experimental state.

I´ll add more documentation as I find more time.

https://git.raise-uav.com/Hermes/fluencyCAD

#fluencycad #sdfcad #solvespace

Basic extrusions are working again with the all new object system. I´m trying to write the code as transparent as possible. This helps me picking up the project after longer pauses and others jumping in should have a good time too :D

I´ll mirror the repo to github once its usable for some basic tasks..

So far these are the components:

• Project: Main File
• Timeline : Used to track the steps
• Assembly: Uses Components and Connectors to form Assemblies
• Component: Container for multiple smaller elements "part"
• Connector: Preserves connections between parts even if the part in between is deleted
• Code: A special type that directly builds bodies from sdfCAD code.
• Body: The 3D meshed result from sdfCAD (blue in 3d view)
• Sketch: The base to draw new entities.
• Interactor: A special component mesh that is used to manipulate the bodies in 3d view.

#solvespace #freecad #sdfcad #cadtools

Ever since I worked on #sdfCAD¹ I have waited for the moment I could actually use #sdf's (signed distance functions) for my research. I know it would come. Today is that day. 🤩

This is for my last #PhD publication I'm working on.

¹https://gitlab.com/nobodyinperson/sdfcad

#meteorology #geoscience #PhDLife #Python #matplotlib #CO2

Pushed fluencyCAD a tiny bit forward with a basic rewrite of the sketch widget.

Less code and prettier to work with internally.

#fluencycad #sdfcad
