Logic Analyzer Shootout: Saleae vs Cheap Clones vs DIY

Photo by Jou00e3o Victor on Pexels.com The red LEDs blink like a heartbeat on a 3am bench. Wires snake across the table, curling around every cup of coffee and screwdriver. Somewhere, a microcontroller coughs data into the void. You lean in closer. The thing you trust most may not be telling the whole truth. Logic analyzers aren’t glamorous. They don’t get likes. They don’t make TikTok videos. But when a digital system hiccups, when a sensor spits out nonsense or your SPI bus is […]

https://cha1nc0der.wordpress.com/2026/01/03/logic-analyzer-shootout-saleae-vs-cheap-clones-vs-diy/

HabrMay 22, 2025

Создание анализатора верхнего уровня для логического анализатора Saleae

Компания Saleae производит логические анализаторы и предоставляет программу Saleae Logic 2 для отображения, анализа и логгирования данных. Logic 2 поддерживает разнообразные интерфейсы и протоколы и их декодирование. Для расширения функций анализатора в Logic 2 появилась возможность создания своих обработчиков и декодеров протоколов. В представляемом материале рассматривается создание своего декодера - анализатора верхнего уровня (HLA). Зачем? Например, есть последовательность передаваемых по SPI байт. Стандартно, при правильной настройке, вы увидите значения этих байт. Но, может возникнуть вопрос интерпретации полученных данных. Декодер может помочь в выводе данных в удобном виде и/или упростить анализ (reverse engineering) неизвестного протокола.

https://habr.com/ru/articles/911946/

#saleae #логический_анализатор #phyton #программирование #reverseengineering #интерфейсы

Создание анализатора верхнего уровня для логического анализатора Saleae

Компания Saleae производит логические анализаторы и предоставляет программу Saleae Logic 2 для отображения, анализа и логгирования данных. Logic 2 поддерживает разнообразные интерфейсы и протоколы и...

Хабр
Show threadmblshaMar 15, 2025

Making address transmissions to be single 16-bit packets enables easy value search in #saleae Logic and saves a few nanoseconds between transmissions.

Also this Z80 variant has a weird counter on the address pins after reading the first instruction, will need to decode it more carefully later.

mblshaMar 15, 2025

Turns out it’s possible to serialize data to 100MHz UART on the FPGA side, and have #saleae correctly decode it with 500MS/s sampling rate.

(screenshot is from Sharp PC-G850's Z80 system bus, with selected address encoded to UART)

Tom SchoutenDec 16, 2024

Does anybody have a reverse engineered spec of the current Saleae Logic2 .sal format?

I understand their point of not releasing spec, I just disagree and want to parse my own files anyway. And yeah I know that export is possible it just adds too much friction.

#saleae #electronics

fookerSep 30, 2024

A few days ago, I fried my #saleae pro logic 8. I've bought the device over 8 years ago. This was quite a downer, as the device is quite expensive and I've used it just for non-commercial stuff.

I've chatted with support about how I can buy a replacement. I did not expect much, as this was clearly my fault and the device was way beyond warranty and I even could not find the receipt.

They immediately offered to send out a replacement part without any charge! This is just awesome.

Paula MaddoxSep 2, 2024
Just spent an hour chasing a problem with a DAC output, it was a bit wobbly and didn't reach the full 3.3V.
Just by chance I swapped the inputs round on my Saleae Logic Pro and the fault went away...
Swapped back and it returned, so it looks like I have a bad channel :(
#Saleae
Show threadcliffleJul 19, 2024

Success!

At bottom: what Saleae Logic shows after trimming data from a capture.

At top: the "trimming" is an illusion, Saleae actually stores more signal than you asked for, and it can be revealed through a simple file rewriter. Hope it wasn't, like, secret.

This behavior is controlled by ~3 fields in the analog capture file, and looks deliberate. It seems difficult to achieve by accident.

#saleae

Luke Switzer 🅅Jul 17, 2024
Got a bricked #ticwatch spitting out some data. Likely its last words just spoken though the #saleae 🪦 Proper lunch break ✔️ #reverseengineering
Xasin, Neira & MeshJun 11, 2024

Aaaannnd we caved and bought a set of #sensepeek #pcbite probes, the 6019 kit. It'll go great with our #saleae and #analogdiscovery3 <3

And thanks to that we're reaching the point of wanting to buy fancy *boxes* for the fancy equipment - a nice metal carry-case and some Cut-And-Peel shadow foam, make a nice multi-layer storage compartment for the small clip-probes and bigger oscilloscope leads, maybe the AD3 adapter boards a layer below...
