cnx-software.comSupTronics X1208 – A UPS + M.2 NVMe SSD HAT for the Raspberry Pi 5
SupTronics X1208 – A UPS + M.2 NVMe SSD HAT for the Raspberry Pi 5
The SupTronics X1208 is a UPS and M.2 NVMe SSD HAT for Raspberry Pi 5 designed to offer fast storage and protect the system against data loss during power outages for Edge Computing, NAS, data logging, and other always-on applications. The HAT draws up to 5V/5A from the USB-C port, which charges a 21700 lithium-ion battery (1.5A) and powers the Raspberry Pi 5 directly through the 40-pin GPIO header, eliminating the need for extra cables. It also features an M.2 M-key NVMe slot supporting 2230/2242/2280 SSDs up to 4TB with PCIe 2.0/3.0 speeds. The UPS supports power switching, auto power-on, safe shutdown on low battery, and GPIO-based power/charging control, along with power loss detection. The X1208 board is also equipped with a Maxim fuel gauge I2C chip for battery voltage and capacity monitoring. SupTronics X1208 UPS + M.2 HAT specifications: Compatibility – Raspberry Pi 5 Model B Storage – M.2 M-key
