J'ai reçu les PCBs pour faire un HPDisk http://www.dalton.ax/hpdisk/ , c'est un émulateur de lecteur de disquettes avec une interface #GPIB qui va me servir pour sauvegarder les configurations de mon analyseur logique #HP 1630G, sans cela il faut tout reparamétrer à chaque allumage !
#logicanalyzer

🇺🇦 haxadecimal 🚫👑Dec 7

I finally will have enough HP/Agilent/Keysight 40-pin logic analyzer pods, the 40 pin shrouded header to 17 flying lead probe cables, because I found some used ones at a decent per-unit price. The only problem is that I had to buy over 100 of them to get the decent price.
The reason to have more pods than the logic analyzer pod cables is that it's convenient to leave pods wired to prototypes.
I also got some used grabbers, but not enough for 100 pods.
#LogicAnalyzer #Agilent #Keysight

LinuxGizmos.com Nov 8

SLogic16U3 USB3 Logic Analyzer Combines Compact Design with 3.2 Gbps Bandwidth

https://fed.brid.gy/r/https://linuxgizmos.com/slogic16u3-usb3-logic-analyzer-combines-compact-design-with-3-2-gbps-bandwidth/

Laurent FRANCOISE Nov 8

Quête annexe pour la remise en route du #heathkit H88 , j'ai ressorti mon analyseur logique #hp 1630G et j'ai assemblé les câbles qui me manquaient (j'en ai monté 4 sur les 7 modules de l'analyseur, ça fait déjà pas mal de connecteurs à sertir !)
J'ai aussi fait un adaptateur pour le #Z80, avec ça je devrais voir ce que fait le CPU quand l'ordinateur démarre (car oui il démarre mais le programme semble tourner en boucle quelque part !)
#retrocomputing #logicanalyzer

Somē Nov 6

What I've been working on for the past 2 weeks 😄 Introducing the third iteration of Lookshi, a portable mini logic analyzer with a max sampling rate of 7Mhz based on the STM32F103.

Here are some pics of Lookshi on a breadboard or two.

Firmware and schematics: https://codeberg.org/some/lookshi

#embedded #embeddedprogramming #microcontrollers #stm #stm32 #stm32f103 #logicanalyzer #project #maker

Mark J. Blair Oct 8

Hey #testequipment nerds! Did #HP or #Agilent make any #logicanalyzer models which provided two clock inputs per 16-bit, 40-pin probe cable? My termination adapters provide for two clocks, but my analyzer and all of the analyzers mentioned in the termination adapter manual only have one clock input per cable.

https://www.eevblog.com/forum/testgear/hpagilent-logic-analyzers-with-2-clocks-per-16-channel-probe/msg6062547/#msg6062547

HP/Agilent Logic Analyzers with 2 Clocks per 16 Channel Probe? - Page 1

dok Sep 30

I started making a clone of "Logic2" (a commercial logic analyzer software) based on libsigrok and GTK4.

This is an experiment and merely a reason to learn GTK4.

It's not really functional yet.

#gtk4 #logicanalyzer #sigrok

🇺🇦 haxadecimal 🚫👑Sep 17

Anybody got a #Agilent or #Keysight 16901A, 16902B, or 16800-series logic analyzer,working or not, that they're willing to part with relatively cheaply? I'm looking for a parts donor, specifically for the front panel, for my 16902B.
If it's a 16800-series, it would be best if it had the touchscreen option, which was standard on the 16901A and 16902B.
The other 16900-series models, even the 16902A, don't use the same front panel.
#LogicAnalyzer

Cupropituvanso Draco Feb 23

Gestern beim SFD Tech Treff:
Analysiere UART Signal beim Midland M-5 CB Funkgerät zwischen Handmike mit Display und Funkgerät.
0xFE 0x03 0x02 0x09 0x09 ^^

Ziel: Neues CB Gateway :)

#cbradio #logicanalyzer #hacking #segfaultdragons #electronics

🇺🇦 haxadecimal 🚫👑Jan 31

The battery for the CMOS/RTC in John's Agilent 16902B #LogicAnalyzer mainframe is apparently dead, and the Agilent License Manager bitches about the date and that we may be trying to cheat the licensing, so we started taking the mainframe apart to replace the battery. The service manual doesn't mention a battery, but explains the steps to get the motherboard try out. The installation guide does mention the battery (CR2032, as expected).
1/
