turtleNew Year is coming.
#yolochka #yolochka_remastered #keyboard #keyboards #ergosplitkeyboard #ergosplitkeyboards
One of the Kometa builds from group buy. Kometa's github - https://github.com/inpudiy/KOMETA/
#kometa #keyboard #keyboards #ergosplitkeyboard #ergosplitkeyboards
Another approach - silikon moled bottom and filler between PLA switchplate and PCB. Definetely can say, that TPU switchplate anyway better.
#keyboard #keyboards #ergosplitkeyboard #ergosplitkeyboards #MOKETA
Soldered 603035 600 mAh lipo battery. Actually in current case model allow to place up to 803035 and if modify models up to 103035.
Case designed with special stands so keyboard can be placed directly on laptop.
Finished MOKETA case. All fills made from TPU, case in PETg. Sounds not bad I think. But because of battery area is empty now then it feels.
Modeled and printed MOKETA bottom. It has TPU printed unslippery strips 2mm width and 18mm spacing, so MOKETA can be used on any laptop placed directly on the keyboard area.
Sound difference between moketa and epomaker x aula F75. But you also need to mention that MOKETA has not finished case build.
Reprinted switchplate in TPU. Also tired place that white sheet between pcb and switchplate, but it too thick and switches are not in contact with hotswaps. Need to find more thin one, but it looks promising. TPU switchplate also looks and sounds good.
#MOKETA #DIY #keyboard #unibody #monosplit #ergosplitkeyboard
Decided to reprint switchplate in TPU (4.8 mm) and also print with same TPU but as different element some layer 0.2mm that will be placed between PCB and switchplate. Made cuts in switchplate. Don't know why, but did.
