"I need a nuclear reaction to generate the 1.21 Gigawatts of electricity that I need" - Doc Brown
#electronics
#electrogirl
#backtothefan
#bttf

Trace layout is definitely easier using KiCad. Still, I finally managed to finish it! 😵
#circuit
#electronics
#electrogirl
#freehand

3 hours in, I'm thinking maybe the computer would have been faster, but I didn't feel like screening it today. The pure focal energy of a blank page is unbeatable though.
#handson
#penandpaper
#dotboard
#pcb
#notpcbreally
#design
#electronics
#electrogirl

Motion detector test tip:
To map out the detection zone for any IR-based motion detector, fill a small plastic bottle (e.g. a pill bottle that seals well) with boiled or hot water, and duct tape it to the end of a long stick. Standing out of range of your sensor, gradually work your way in, waving the hot point around until it triggers. This may be more useful information to someone using PIRs to track the movement of small warm-blooded mammals, but whatever.
#electrogirl
#maker
#scientist

Day 2 of making the rat scarecrow from hell...
#ratscarecrowfromhell
#theblackieproject
#maker
#electrogirl

No crackling or unsanctioned diddlybop in my diddlybop, please!
#shielding
#retrofitting
#diy
#electrogirl

Adhoc top-mount screwless slide-lock bay enclosure extension for my split power supply mod. All it needs now is a little aesthetic polish and it's done. Might add a single screw on the outside to lock it closed.
#electronics
#electrogirl
#enclosure
#upcycled
#diy

Presently: making a split 20V/5V1 DC adapter from a 32V one, some bucks, and scrap ABS...
#labgirl
#electrogirl
#electronics
#maker
#diy

This is what I do.
I sort modules
and look cute.
#labgirl
#electrogirl
#electronics
#sorting
