Gave it a quick clean (Dasty) before putting everything back together again. No RGB mod needed as I will mod the CD dock for RGB. Then I remembered I should do the jailbar fix first! Turned it on and don't really notice jailbar, but weren't they more visible with RGB? #pcengine #turbografx16 #PCエンジン
Recapped the #turbografx16. On the PAL TG16 I destroyed a few pads. Most caps are connected on the top on one side. So it is better to heat the pad topside and remove it. Also make sure to suck out the solder on those ads before putting new ones. Will make it easier. #pcengine #PCエンジン
Capmapped (will be submitting this word to Meriam Webster's new words of the year!) the NEC TurboGrafx-16. Will be recapping this one next. #retrorevival #pcengine #turbografx16
Never seen something like this before. IC102 has a plastic metal shield thing? U populate I pads. 23C1000 mask rom, uPD65006 CMOS gate array (?) and space for an Als245 for mapper logic? #pcengine #PCエンジン #turbografx16
I think I read somewhere that the boards between the US and PAL #turbografx16 were quite similar with so.e small differences. But these look quite different, unless they were talking about the shape... #pcengine #PCエンジン
Opened up the US #turbografx16, the inside of the shell looks a lot more polished compared to the PAL version. #pcengine #PCエンジン
Updated the cap map, v1.1 now. Forgot to add the cap numbers of the two lower caps and there was one more sneaky hidden cap on the little power socket PCB. Also changed the color of 1 cap because it was too similar to another. #pcengine #turbografx16 #tg16 #PCエンジン

Cap map for the NEC TurboGrafx (PAL) HES-TGX-11

#pcengine #PCエンジン #tg16 #turbografx16 #retrorevival

Some time later... Well, here she is. Might as well make a cap map and recap it. Anyone notice any differences from the US board, apart from the crystals? Maybe I should NTSC-ify it... #pcengine #PCエンジン #turbografx16
