I just finished a big update for my LR2052 storage box system 😊 All series are now at revision E, and I added new plain storage box variants for every height.
I also included a few requested tweaks, like open-bin boxes with a higher front wall.
There are now 8000+ files (3MF + STEP, ~32GB) available:
https://sb.metikumi.com/
I’m still working on updating Printables, blocked due to size limits.
I just released the first batch of revision E storage boxes. I rebuilt the pipeline to generate STEP and 3MF files, and the quality is noticeably better.
New:
• plain variants without label area
• a minimalistic series label
• meshes that follow the original surfaces more closely
Take a look: https://sb.metikumi.com/browse/Models/
I’ve just made a small update to the download area for the LR2052 Storage Boxes System. It should fix the issues some of you ran into downloading the large multi-GB packages.
If you had trouble before, I’d really appreciate it if you could try again and let me know how it goes.
Switching to the high-flow nozzle on the PrusaXL made a huge difference in print speed! I printed 18 sturdy storage boxes using leftover Fiberlogy PETG in just 14 hours. These are structural, high-quality prints with excellent layer adhesion.
One of my favorite features of the PrusaXL is spool join! I can load up all my nearly empty spools, hit print, and let it do the rest. Here’s a batch of storage boxes printed with leftover PETG—Fiberlogy Vertigo, Prusament Galaxy Black, and Anthracite Grey.
This model (LR2052-112D) was printed 18 times and is part of the free storage box set.
Leftover PETG from my large planter project? No problem—I kept my printer busy with storage boxes! The filament is Fiberlogy PETG Vertigo, a stunning dark gray with a subtle glitter effect. ✨
This model (LR2052-132D-G3) was printed six times and is part of the free set in my storage box system. Check it out: https://lr2052.luckyresistor.me
Curious about the latest changes to my storage box system?
I’ve just published a detailed post covering all the updates, including what changed and why.
Read all about it here:
https://luckyresistor.me/2024/07/21/the-2024-update-of-the-storage-boxes-system/
Let me know if I missed anything!
Storage Boxes Feature Comparison #2
(Revision C vs. D)
In Revision C, the label area corners lacked perfect arcs with consistent thickness, and the 90º angle slowed down printing.
Revision D introduces soft transitions and a 45º angle, solving these issues, though it slightly shortens the label area for one-unit wide boxes.
Storage Boxes Feature Comparison #1
(Revision C vs. D)
In Revision C, the groove for aligning storage boxes on the rail grids was a weak spot. By lowering the point where the gap is bridged in Revision D, I’ve been able to strengthen this connection.
The geometry step ensures the slicer aligns the bridges differently at the edge and center, enhancing stability.
