Watch a Complete Reflector Telescope Machined from a Single Block of Glass

If this is the easy part of making a complete reflector telescope from a single piece of glass, we can't wait to get a load of the hard part!

A little backstory may be in order for those who don't follow [Jeroen Vleggaar]'s Huygens Optics channel on YouTube. A few months ago, he released a video discussing monolithic telescopes, where all the reflective and refractive surfaces are ground into a single thick block of glass. Fellow optical engineer [Rik ter Horst] had built a few tiny monolithic Schmidt-Cassegrain reflectors for use in cube sats, so [Jeroen] decided to build a scaled-up version himself.

The build starts with a 45 mm thick block of crown glass, from which a 50 mm cylinder is bored with a diamond hole saw. The faces of the blank are then ground into complex curves to reflect incoming light, first off the parabolic rear surface and then onto the hyperbolic secondary mirror ground into the center of the front face. A final passage through a refracting surface in the center of the rear face completes the photons' journey through the block of glass, squeezing a 275 mm focal length into a compact package.

All this, of course, vastly understates the work required to pull it off. Between the calculations needed to figure out the surface shapes in the first place to the steps taken to machine a famously unforgiving material like glass, every step is fraught with peril. And because the design is monolithic, any mistakes mean starting all over again. Check out the video below and marvel at the skills needed to get results like this.

What strikes us most about [Jeroen]'s videos is the mix of high-tech and age-old methods and materials used in making optics, which we've seen him put to use to make everything from tiny Tesla valves to variable-surface mirrors.
