One of the weirder things I've done: ATI Radeon HD 4670 GPU, S-Video out to a USB capture card, viewed in VLC.

At least I know the S-Video output *works*, but... yeah, I can't read that.

#linux #svideo #retrocomputing #pc

Adaptor SCART tată-mamă la 3x RCA și S-Video cu comutator Goobay

https://habo.ro/adaptor-scart-tata-mama-la-3x-rca-si-svhs-cu-comutator-goobay/

#AdaptorScart #Goobay #RCA #SVideo #ConecticaAudioVideo #OferteOnline #CumparaturiOnline #ProduseNoi #TechRomania #Tehnologie #TehnologieRomania #ProduseDeCalitate #UtilSmartPractic #MagazinOnlineElectronice #MagazinOnline #ShopHaboRo #HaboRo #Habo #MagazinHaboRo

Samstag Löt Projekt, Umbau eines N64 NTSC SVideo Kabel zu ein PAL SVideo Kabel. Einlöten von 75Ohm Widerstände und 220uF und 68nF Kondensatoren. SVideo ist leider das beste, was man aus einer N64 PAL Konsole bekommt, Konsole kann kein RGB. Das analoge SVideo Signal wird mittels GBS-Control Pro Upscaler auf HDMI gewandelt, und dann am TV dargestellt.

#nintendo #n64 #Nintendo64 #retro #gbscpro #gbscontrol #sVideoMod #SVideo #DenshaDeGo #retrogaming

Watching some demos on the 800XL

#Atari800XL #Atari #A8 #demoscene #scenedemo #demo #video #PVM #CRT #SIO2SD #vintagecomputing #retrocomputing #retrogaming #svideo #chromaluma

Learning: Let's fix the GP2X breakout board

https://makertube.net/videos/watch/3e925014-4b9e-4970-bf26-add74a948e21

#vickytwenty board finally booting! With a sovietic 6502 clone in it, a ridiculous stack of sockets for the ROMs (waiting for my adapters from JLCPCB to arrive to fix this) and a B/W image (I did the #svideo mod, but connected only the luma signal for testing).

The character rom has a bodge wire on it for the second /CS signal. I totally forgot this one was a 2332 and required both select signals to be handled by the VIC.
