Accessing the openFPGA BRIDGE part 2 👾

https://mytube.malenfant.net/videos/watch/d5d2a167-7aa3-4589-adbc-0b93a5740ec4

Another full day of debugging and understanding more and more about the ‘Right Way™’ to do things in #Verilog and…boom! 💥

My gfx chip is now working correctly based on the 4 registers it exposes. I still don't have a working CPU yet but this is using a little FSM to drive the chip.

This is so much fun…

#AnaloguePocket #OpenFPGA #ProjectFreedom #pfx1

👾 Just posted pf-dev-tools v1.0.6:

✅ Fixed a bug in argument parsing for pf clone.
✅ pf install and pf eject now take full paths for volumes.
✅ Added support for PF_CORE_TEMPLATE_REPO_FOLDER to use local core template directory.
✅ Improved some documentation in README.

https://pypi.org/project/pf-dev-tools/

#OpenFPGA #FPGA #AnaloguePocket #ProjectFreedom #pfx1

👾 Just posted pf-dev-tools v1.0.5:

✅ Added better user feedback when docker image needs downloading.
✅ Renamed Environment to SConsEnvironment.
✅ Added an automatic check for when updates are available.
✅ Improved the way some error messages are displayed.

https://pypi.org/project/pf-dev-tools/

#OpenFPGA #FPGA #AnaloguePocket #ProjectFreedom #pfx1

Introducing pf-dev-tools 🎉

This is the toolchain I put together to build and package my fantasy console core on the pocket. It's entirely Python-based thanks to SCons which is built in.

Super simple Makefiles. One line core building/packaging/installing. Did I mention Python?

Anyway, it's also used in the sample code for the openFPGA tutorials.

https://didier.malenfant.net/blog/projectfreedom/2023/06/07/Introducing-pfDevTools.html

#AnaloguePocket #OpenFPGA #FPGA #Python #ProjectFreedom #pfx1

Here we go… first bit of ‘real’ work done on the graphics chip. It takes two 16-bit values as input and displays them as a debug overlay on the screen.

This will be super useful for debugging the core…

#ProjectFreedom #pfx1

👾 New blog post: Stars and Sprites 👾

I think I now have enough #Verilog knowledge to get started on the real graphics chip for the pfx-1 console.

Wish me luck!

https://didier.malenfant.net/blog/projectfreedom/2023/05/25/stars-and-sprites.html

#AnaloguePocket #OpenFPGA #FPGA #IndieDev #ProjectFreedom #pfx1

Hardware sprites, ultra-mini Copper, LFSR star field… I‘ve learned a lot so far. Next stop, reading data over the APE and interfacing with a couple of different types of RAM.

Oh working over different clock domains too!!

#OpenFPGA #AnaloguePocket #AnaloguePocketDev #ProjectFreedom
