@tmiller thanks! The #Pixelblaze Sensor Expansion Board by @wizard has a microphone, 3.5mm line-in jack, and a small MCU that handles sampling the input into a 32 frequency bin FFT that you can use in patterns. The javascript patterns can be written and edited live in a web app over wi-fi, hosted on the Pixelblaze's ESP32. It's brilliant in every way.
https://shop.electromage.com/products/pixelblaze-v3-standard-wifi-led-controller
https://shop.electromage.com/products/pixelblaze-sensor-expansion-board

Pixelblaze V3 Standard - WiFi LED Controller

Jason Coon Mar 4

Sorry if you're tired of these, I'm having fun tweaking sound-reactive #PixelBlaze patterns. 😁
Get your own: https://lectronz.com/products/fibonacci256-expanding-166mm-disc-w-256-rgb-leds

Jason Coon Mar 3

Fibonacci256 Expanding HDR is now available!
It's music-reactive & powered via #PixelBlaze by @wizard so you can edit & write new patterns in a web app over wi-fi.
Get yours here: https://lectronz.com/products/fibonacci256-expanding-166mm-disc-w-256-rgb-leds

Jason Coon Feb 28

RE: https://leds.social/@jasoncoon/116026291372431977

Fibonacci256 Expanding HDR is now available!
They're music-reactive and powered via #PixelBlaze by @wizard so you can edit and write new patterns in a web app over wi-fi.
Get yours here: https://lectronz.com/products/fibonacci256-expanding-166mm-disc-w-256-rgb-leds

Jason Coon Feb 10

@xabean ha, I'm so glad you noticed! I spent longer than I care to admit trying to get them perfectly aligned, although I don't think my camera was perfectly "trammed" to the surface.
The two are being driven by separate but synced #Pixelblaze, but the pattern with particles emitting from the center does use RNG which is apparently not synced.

gallaugher Jan 20

Such fun giving a seminar on #PixelBlaze to the women of Boston College's Girls Who Code chapter. @wizard your gear continues to inspire & empower. Hack on!

Show thread

Kernel Bob

Jan 19

The LED cube's base came out okay. The Pixelblaze fits snugly, and the back panel looks better than it needs to. The printer is still printing the rest of the parts.

All glory to @jasoncoon for designing and manufacturing the LED cube. I'm just designing a new enclosure for it.

🧵 14/N

#PixelCube #Blinky #3DPrinting #Pixelblaze

gallaugher Jan 19

Gnarly wiring on the 10x5x5 #PixelBlaze LED cube. I really need to find time to solder this so I don’t need to constantly fix when someone moves this improperly.

Jason Coon Jan 10

#Genuary 2026 Day 10: Polar Coordinates

Two-dimensional Perlin noise mapped to polar coordinates, rendered using color palettes on a 320mm Fibonacci512 with 512 SK9822-EC20 HDR RGB LEDs with a #PixelBlaze by @wizard

Get your own sound-reactive Fibonacci512: https://lectronz.com/products/fibonacci512hdr

#Genuary2026 #Genuary10 #SciArt #CreativeCoding

Show thread

Jason Coon Jan 4

This is two fifths of a Fibonacci1024 (slices 2 & 3): 410 WS2812 RGB LEDs, matte black LED acrylic diffuser and wall mounting back plate, 476x303mm (18.7x11.9in), audio-reactive, driven with #Pixelblaze. Let me know if you're interested.
