Polémica con el Galaxy S26 Ultra – Su función estrella «Privacy Display» está provocando fatiga ocular y dolores de cabeza

Lo que debía ser la innovación más aplaudida de Samsung para 2026 se está convirtiendo en su mayor dolor de cabeza, literalmente. A pocos días del lanzamiento oficial, una oleada de usuarios del Galaxy S26 Ultra ha comenzado a reportar fatiga ocular, náuseas y cefaleas tras usar el dispositivo. El culpable parece ser el nuevo panel «Privacy Display», una tecnología diseñada para ocultar el contenido de la pantalla a los curiosos, pero que está pasando factura a los ojos más sensibles (Fuente AndroidAuthority).

Esta controversia, se suma a una semana difícil para Samsung tras el error de certificación de Google Play que bloqueó apps bancarias en algunas unidades del S26.

El problema: PWM de baja frecuencia y «texto borroso»

Aunque Samsung promocionó el S26 Ultra como la cima de la ingeniería visual, los entusiastas de la tecnología han descubierto que la compañía sigue utilizando una frecuencia de PWM (modulación por ancho de pulsos) de solo 480Hz, muy por debajo de los estándares de salud ocular que ya ofrecen sus competidores chinos como Vivo u Oppo.

• Parpadeo invisible: Los usuarios sensibles al parpadeo de las pantallas OLED experimentan mareos similares a los de las gafas de VR, ya que el cerebro detecta el ciclo de encendido y apagado de los píxeles aunque el ojo no lo vea.
• Falta de nitidez: Se han viralizado fotos macro que comparan el S26 Ultra con el S25 Ultra, mostrando que el texto en el nuevo modelo parece «sucio» o difuminado. Esto se debe a la Black Matrix, la estructura física necesaria para que funcione el filtro de privacidad, que reduce la claridad de los bordes de las letras.

¿Es un fallo de hardware o de software?

Lo más preocupante para los compradores es que estas molestias ocurren incluso con la función de Privacy Display desactivada.

«Es como si estuvieras mirando la pantalla a través de una lente empañada», comentan usuarios en Reddit.

Dado que la capa de privacidad es una característica física del panel OLED, expertos como el filtrador Ice Universe sugieren que una actualización de software no podrá corregirlo por completo, aunque Samsung podría intentar mitigar el efecto aumentando el brillo artificialmente mediante un parche.

Confusión con los «10 bits»

Para empeorar las cosas, Samsung ha tenido que rectificar sus materiales de marketing. Aunque inicialmente se dijo que el S26 Ultra tenía un panel nativo de 10 bits (1.000 millones de colores), la empresa ha confirmado que se trata de un panel de 8 bits con FRC (una técnica que hace parpadear los píxeles para simular más colores). Este parpadeo adicional, sumado al bajo PWM, es la combinación perfecta para generar fatiga visual en sesiones largas.

La respuesta de Samsung

Ante la presión, Samsung ha declarado que está investigando los reportes, pero mantiene que la pantalla cumple con todos los estándares de seguridad vigentes. Mientras tanto, recomiendan a los usuarios activar el «Escudo de comodidad ocular» y evitar niveles de brillo extremadamente bajos en habitaciones oscuras.

Este «Display-gate» ocurre en un marzo de 2026 donde la industria está bajo la lupa: mientras Apple filtra su iPhone plegable sin pliegues, Samsung se enfrenta a críticas por una pantalla que, por intentar proteger la privacidad del usuario, ha terminado comprometiendo su bienestar.

Micro Music Media Library (2019)

by @protodome

"This is the companion web page for the Micro Music: Exploring the Idiosyncratic Compositional Strategies Encountered in 1-Bit, Limited Memory Environments doctoral project. [...] 1-bit music, generally considered a sub-division of chiptune, is the music of a single square wave. [...] [T]he unique techniques and auditory tricks of contemporary 1-bit practice exploit the limits of human perception. Through layers of modulation, abstraction and clever writing, these compositional methods generate music far more complex than the medium would, at first impressions, indicate..."

https://phd.protodome.com

#chiptune #pwm #bytebeat

Golf im Private Wealth Management ist mehr als ein Hobby auf dem Platz werden Netzwerke gepflegt, Vertrauen aufgebaut und Deals vorbereitet wer Golf strategisch nutzt, stärkt Kundenbindung und Origination zugleich ⛳📊

Hashtags
#golf #pwm #privatebanking #wealthmanagement #businessgolf #netzwerk #banking

Обзор микросхемы DRV8870

DRV8870 - это старая простая микросхема управления коллекторным DC -мотором с токами в обмотках до 3.5 Ампер от компании Texas Instruments. По сути это драйвер H-моста . Причем H-мост встроен прямо внутрь корпуса самой микросхемы. Это полностью интегрированное решение. В этом тексте я произвел обзор микросхемы DRV8870. Посмотрим с какой стороны следует подходить к микросхеме DRV8870.

https://habr.com/ru/articles/952484/

#DRV8870 #hbridge #hмост #stm32 #DevEBoxSTM32F4XX_M_V30 #STM32F407VGT6 #pwm #TIMER #gpio #18650

Simple PWM Filter PCB Build Guide

Here are the build notes for my Simple PWM Filter PCB Design. Below you can see it connected to my Pico Touch Board.

Warning! I strongly recommend using old or second hand equipment for your experiments.  I am not responsible for any damage to expensive instruments!

If you are new to electronics and microcontrollers, see the Getting Started pages.

Bill of Materials

• PWM Audio Filter PCB (GitHub link below)
• 2x Suitable filter components, for example, per channel:
  • 3x 1KΩ resistors
  • 2x 100nF ceramic capacitor
  • 1x 2u2 electrolytic capacitor
• Optional: Pin headers
• Optional: 2x 3.5mm TRS sockets (pcb mounted, see photos for footprint)

Build Steps

Taking a typical “low to high” soldering approach, this is the suggested order of assembly:

• All resistors.
• TRS sockets (if used).
• Disc capacitors.
• 3-way jumper headers (if used).
• Electrolytic capacitors.

Here are some build photos.

If the electrolytic capacitors will be bent over, then they should be bent and soldered in place before the header pins.

Testing

I recommend performing the general tests described here: PCBs.

PCB Errata

There are no known issues with this PCB at present.

Enhancements:

• As previously mentioned it might have been useful to label the left and right channels and use the alternative resistor circuit symbol.
• It might have been useful to include solder jumpers to allow the simple combining of the left and right inputs and outputs
• Some additional connection points for an oscilloscope might have been useful too.

Find it on GitHub here.

Sample Applications

Here are some applications to get started with:

•  Pico Touch Board Audio – 3x 1K resistors, 3x 100nF capacitors, and 1x 2u2 electrolytic per channel.

Experimenter board

Rather than fixed components, it is possible to solder on round pin header sockets to allow components to be pushed into place. This means that it is fairly easy to experiment with alternative component values to see what difference they make.

When doing this, I only soldered up one channel, but joined the left/right inputs and outputs by adding a solder bridge across the pin headers. I also soldered additional pins to the spare GND connections from the second channel. This allows plenty of pin connections for an oscilloscope.

The connections for components aren’t as tight as they could be, especially for low-wattage components with pretty thin legs.

It might be that just continuing to use solderless breadboard for experiments is simpler, but it was pretty useful to be able to leave oscilloscope connections and the input and output connected whilst experimenting.

Board Manufacturing

These boards are sized to allow them to be ordered in a 2×4 panel if required, and still remain within a 100x100mm footprint. I used jlcpcb’s panel options with v-cuts and it was really quite inexpensive to do.

Closing Thoughts

I’m still not sure I really understand enough analog electronics to get the theory of how a dual-stage filter incorporating a potential divider still works, and any simulation is still not quite matching my theory to experiment.

As has been said, “in theory, theory and practice are the same, in practice they are different”.

This might make some proper practicing a bit easier.

Kevin

#filter #lpf #pcb #pwm

Simple PWM Filter PCB Design

Having spent a bit of time attempting (although I’m not sure I’m succeeding yet) to understand how to get a useful filter for my Pico Touch Board Audio, I thought it would be useful to have a simple template PCB that could be used for a range of PWM low-pass filtering options.

This is my design.

• Simple PWM Filter PCB Build Guide

Warning! I strongly recommend using old or second hand equipment for your experiments.  I am not responsible for any damage to expensive instruments!

If you are new to electronics and microcontrollers, see the Getting Started pages.

The Circuit

This is following on from the discussion in Pico Touch Board Audio creating the template for a simple two-stage low-pass filter with an option for including a potential divider resistor to drop the overall voltage too.

I’ve doubled the circuit to allow for stereo in and out if required and have included both 3.5mm TRS sockets and pin jumper headers for both input and output.

It requires no power, being a completely passive filter.

If stereo is not required, then just one of the circuits can be populated – ideally the one connected to the TRS tip.

PCB Design

There isn’t much to this pcb layout really. I was particularly keen to keep the PCB away from specific values of components, so instead used the silkscreen to present a pseudo-circuit diagram to make it clear which components are which.

I’ve also tried to leave enough room for the electrolytic capacitors to allow them to be bent over if required.

Closing Thoughts

With hindsight, I can think of a couple of additions that would have been useful on the silkscreen – labelling which circuit is left and right for example.

And having the boards back, I should have added manual “wavy line” resistor diagrams rather than rectangles, but it is enough for what I need.

And it might have been useful to include some additional test points for connecting an oscilloscope.

Kevin

#filter #lpf #pcb #pwm
