#freecadfriday designing a prototype grinding wheel hub to fit-check to my Unimat #lathe

#machining real one next!

#diy #workshop #freecad

Went on a course trying out svegsvarv/ pole lathe at Långbrogård in Mölnbo Sweden, with Oliver and Raleigh (@(@Wildcraftedhome). An intense but fun weekend learning alot. Makes you eager to build one yourself for sure now when I got a few tools ⚒️🌳
-
___________________________________________
#svegsvarv #polelathe #lathe #woodturning #bowlturning #trähantverk #hantverk #woodbowl #woodwork

Dovetails before and after:

#mill #lathe #cnc #machining #maker

Before and after:
#maker #machining #cnc #lathe #mill

Next, I used 3D printed fixture designed in #freecad to accurately flip the saddle for subsequent #machining of the saddle dovetails.

#cnc #lathe #mill

After zeroing on the 16mm reference, I just had to use the DRO for -10.51mm offset.

#machining #lathe #mill #freecad #cnc

Re-#machining the saddle with the NAHO #mill for my #cnc minilathe.

Used #freecad to first copy the exact bed profile and then calculate what must be the offset between the re-machined V-slot and other flat surface when referenced from a 16mm cylinder.

#mill #cnc #freecad #lathe
