Chopper shaft balancing on an ACROS 595 Plus combine — done in the field, in own bearings. ⚙️

Balanset-1A on a folding table, vibration sensor on a tripod, laser tach on the shaft. Full vibration analysis setup under the machine on the grass.

Heavy steel flails on that drum. Vibration reduced to minimal levels. 📊

#vibrationanalysis #balancing #predictivemaintenance #industrialequipment

⚙️ EKC Engineering balancing a hydrodynamic brake rotor on a custom soft-bearing stand. Balanset-1A as the measurement system. Two-plane vibration analysis at 3864 RPM.

MEMS accelerometers like ADXL335 use a sub-mm silicon plate to capture it all.

#vibrationanalysis #balancing #industrialequipment

Series continues — balancing stand posts. EKC Engineering: "A milled rotor also needs balancing, it turns out."

⚙️ Two correction planes fully compensate dynamic imbalance of a rigid rotor. Balanset-1A does the vibration analysis here on a compact bench setup 🔧

#vibrationanalysis #balancing #industrialequipment

🪜 Upgrade to FRP ladders—strong, corrosion-resistant & built for tough environments. Safety meets performance! 💪⚡

https://accessindustrial.com/en/Product/frp-ladders/

#FRPLadder #FiberglassLadder #IndustrialSafety #WorkplaceSafety #NonConductive #SafetyFirst #ConstructionTools #IndustrialEquipment #ElectricalSafety #HeavyDutyTools #SafetyGear #ConstructionLife #MaintenanceWork #SafeClimbing #LadderSafety #EngineeringTools #FactorySafety

EKC Engineering's balancing machine build continues (Apr 2021).

Hobby software gave up on them, so they got a Balanset-1A kit. Looks rough, works right — vibration analysis results are stable and predictable ⚙️

New design: steel ribbon suspension instead of bearings. CNC aluminum frame, belt drive. Phase is solid, balancing works 🛠️

Sometimes function beats form.

#balancing #vibrationanalysis #industrialequipment #predictivemaintenance #engineering

EKC Engineering built a soft-bearing balancing stand from scratch for a Wankel rotor. CAD design → CNC aluminum machining → two-plane sensor setup. ⚙️

Clean build. For portable work, a Balanset-1A with vibration analysis sensors does two-plane balancing without a dedicated stand. Different tools, same physics. 🛠️

#balancing #vibrationanalysis #industrialequipment #predictivemaintenance

Balancing a threshing drum on a Don-1500B combine using a Balanset-1A ⚙️ Two vibration sensors, laptop on a folding table in the field.

Two types of imbalance exist — static (mass center offset) and moment (inertia axis skew). Both show up on long drums like this, so two-plane vibration analysis is the way to go. 🛠️

Portable setup, real measurements, field conditions 📊

#vibrationanalysis #balancing #predictivemaintenance #industrialequipment #agriculture

Effective Storage Solutions for Maintaining Organized Workshops

📰 Original title: Top Storage Systems That Help Workshops Stay Organized

🤖 IA: It's not clickbait ✅
👥 Usuarios: It's not clickbait ✅

View full AI summary: https://killbait.com/en/effective-storage-solutions-for-maintaining-organized-workshops/?redirpost=9eba4578-ff94-497e-9b7d-7b3fd8f0f52c

#technology #workshoporganization #toolstorage #industrialequipment

Built for strength and efficiency, this heavy-duty shredder handles plastic, film, bottles, and other waste materials with ease. High torque, stable performance, and durable blades ensure consistent size reduction for smoother downstream processing.

#WasteShredder #RecyclingMachine #PlasticRecycling #IndustrialEquipment #Machinemg #SustainableRecycling
